Поз.
Артикул
Описание
5
ELECTRONICS DOOR CONTROL
5
ELECTRONICS DOOR CONTROL
8
VALVE
8
SOLENOID VALVE , Replaced By: A0007607078
9
DAMPER
10
VALVE 3/2-WAY VALVE
11
CONNECTOR
12
LOCKING MECHANISM
15
SWITCH , Replaced By: A0008213371
15
PRESSURE WAVE SWITCH PRESSURE WAVE CONTROL, Replaced By: A0008214771
15
PRESSURE WAVE SWITCH , EXHAUST STOCK OF OLD PART NUMBER FIRST
17
SWITCH
20
PUSH BUTTON SWITCH UNIPOLAR
21
SCREW PLUGROCKINGER,TYP 59 U150
21
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
23
VALVE (THROTTLE VALVE)
24
VALVE SHUTTLE VALVE
25
HOSE1M, ORDER BY THE METER
26
SEAL RING LINE CONNECTION
32
FITTING DIA., 6MM, M12X1,5
35
FITTING DIA., 6 MM, M5
38
T-FITTING
38
FITTINGM 12X4.5, D 6 MM
38
T-FITTING FROM EMERGENCY COCK TO REGULATING VALVE 6 MM
39
ELBOW FITTING DIA., 6MM
40
VALVED6 MM
44
SCREW CONNECTION DELIVERY LINE 6 MM
54
SWITCH (DIAPHRAGM) 4.0 BAR
54
SWITCH0,5 BAR
60
FITTING
71
DOOR CYLINDER TOP,ABOVE DOOR
75
SWITCH0,5 BAR
999
ELECTRIC CABLE DOOR CONTROL
999
ELECTRIC CABLE POTENTIOMETER
999
SWITCH SOLENOID SWITCH
999
THREADED UNION
999
SLEEVE DIA., 6 MM, M10 X 1
999
CONTACT SPRING0,5 - 1,0 MM2
999
SUPPORTING PLATE DOOR I
999
SUPPORTING PLATE DOOR I
999
SUPPORTING PLATE CONTROL UNIT FOR DOOR WINGS,SEPARATE
999
SUPPORTING PLATE DOOR I
999
SUPPORTING PLATE DOOR I
999
SUPPORTING PLATE DOOR I
999
ELECTRIC CABLE DOOR CONTROL
999
ELECTRIC CABLE POTENTIOMETER
999
ELECTRIC CABLE DOOR CONTROL
