Поз.
Артикул
Описание
5
FUEL LINE15X1.5, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
8
FUEL LINE8X1, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
22
PLUG CONNECTION8X1, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.02.2010
22
COUPLING
24
RIGHT-ANGLE PLUG
26
PLUG CONNECTION
40
FITTING FUEL LINES
42
FITTING RETURN LINE
90
NUT
90
UNION NUT FEED LINE
92
NUTBL 8
92
UNION NUT RETURN
100
VALVE8X1
102
VALVE
102
VALVE CHECK VALVE
102
NON-RETURN VALVE8X1, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.02.2010
104
VALVE
106
SHUT-OFF VALVE , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.02.2012
106
VALVE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.01.2012
106
VALVE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.06.2006
131
WASHER BRACKET TO FUEL TANK SUPPORT
251
BRACKET FUEL-OIL LINES TO SUBSTRUCTURE
258
BRACKET ELECTRIC CABLE MOUNTING
360
CONNECTOR LINE CONNECTION
600
NUT COVERING TO CAB FIRE WALL
601
RIVETED NUT REFRIGERANT LINE TO CAB REAR PANEL
605
NUT RELAY TO BRACKET M5
605
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
606
NUT , Replaced By: N913023006001
606
NUT BRACKET TO FIRE WALL
606
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
606
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
608
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
608
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
610
NUT
610
NUT BATTERY CABLE
610
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
700
705
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
705
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
705
HEXALOBULAR BOLT ELECTRIC CABLE MOUNTING M5X10,V 213244
706
SCREW BRACKET AND CLAMP M6X20
706
SCREW , Replaced By: N914146006102
706
SCREW LICENSE PLATE TO BRACKET
706
HEXALOBULAR BOLT LINE MOUNTING M6 X 25
706
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
706
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
708
SCREW BRACKET TO SIDE MEMBER M8X20
708
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
708
SCREW BRACKET TO CAB REAR PANEL M 8X20
708
SCREW 3/2-WAY VALVE TO BRACKET
710
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
710
SCREW BRACKET TO SIDE MEMBER M10X35
710
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
714
SCREW PLUG FUEL TANK
714
SCREW PLUG, FILLING OIL COOLER
808
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
812
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
812
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
812
CLAMP
815
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
818
CLAMP BRAKE HOSE BRACKET
820
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
822
MOUNTING CLAMP22/15
822
CLAMP22/15, Replaced By: A0019951442
825
CLAMP HOSE TO FLANGE AND TO VALVE
828
MOUNTING CLAMP28/15
828
CLAMP28/15, Replaced By: A0019951842
830
CLAMP AT SUPPORT 30/15MM, Replaced By: A0019951942
838
CLAMP LINE MOUNTING
838
CLAMP , Replaced By: A3829950701
900
CABLE TIE IONIC EXCHANGER 380X7.8MM
900
CABLE TIE LINE MOUNTING 375X8.4MM
900
LOOM TIE
