Поз.
Артикул
Описание
5
LIGHTING UNIT FRONT RIGHT
5
LIGHTING UNIT FRONT LEFT
10
BRACKET HEADLAMP
15
BULB24V,70W
18
LAMP SOCKET
20
BULB24 V
23
SEAL
26
REFLECTOR
28
TS-CAP HIGH BEAM
28
TS-CAP LOW BEAM
30
RETAINING CLIP
32
JOINT BALL HEAD TOP M6X76
32
BRACKET PARTS KIT,BOTTOM
100
BLINKER LAMP FRONT RIGHT, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.01.2006
100
BLINKER LAMP FRONT LEFT, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.01.2006
100
BLINKER LAMP FRONT LEFT, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 02.01.2006
100
BLINKER LAMP FRONT RIGHT, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 02.01.2006
105
YELLOW BULB TAILLAMPS 24V-21W
110
SOCKET BLINKER LAMP
150
FOGLAMP LEFT
150
FOGLAMP RIGHT
160
LENS LEFT
160
LENS RIGHT
165
SEAL LEFT AND RIGHT
170
COVERING LEFT AND RIGHT
175
RETAINING CLAMP. SPRING , Replaced By: A1408260284
180
BULB24V,70W
200
RIM TOP LEFT
200
RIM TOP RIGHT
205
EXTERIOR LAMP
205
POSITION LAMP. EXTERIOR LAMP POSITION LAMP LED
210
HEXALOBULAR BOLT SWITCH TO INSTRUMENT PANEL M4X16
210
TAPPING SCREW3,5X13
212
CLIP FASTENER
230
DAYTIME RUNNING LIGHTLED
233
PIN BUSHING HOUSING 3-POLE
236
CORE BUNDLE SEALING1.0-2.5 MM2
236
GASKET. BLIND PLUG
239
PIN BUSHING1,0 - 1,5
