Поз.
Артикул
Описание
7
8
HOSE , Replaced By: A6254660381
9
HOSE FROM LINE TO OIL TANK
17
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
20
NUT LINE CONNECTION
20
UNION NUT LINE CONNECTION, Replaced By: N000000006243
23
GLAND , Replaced By: A0019901267
30
LINE (DELIVERY AND SUCTION LINE), ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
31
LINE15X1.5, ELIMINATED - NO LONGER REQUIRED
31
FUEL LINE. HOSE FUEL TANK TO RING MOUNT 12 X 15 MM, ORDER BY THE METER, Replaced By: A0004763601
31
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
34
UNION NUTAL22
34
NUT LINE CONNECTIONS AL 15
34
UNION NUT LINE CONNECTION
37
CUTTING RINGBL22, Replaced By: A0019970317
37
GLAND LINE CONNECTION
37
GLANDBL22
37
GLAND (DELIVERY AND SUCTION LINE) BL15
45
FITTING
45
FITTING AT STEERING GEAR
45
SCREW-IN FITTING , Replaced By: N003901015005
45
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
45
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
45
FITTING POWER STEERING PUMP
80
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
80
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
80
CLAMP22/15, Replaced By: A0019951442
80
CLAMP AT SUPPORT 30/15MM, Replaced By: A0019951942
80
CLAMP COMPRESSED AIR LINE TO TRANSMISSION COVER 25/15
80
CLAMP LINE MOUNTING
80
CLAMP BRAKE HOSE BRACKET
80
CLAMP LINE MOUNTING 15-18 MM,V 207570
80
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 25/15 MM
80
MOUNTING CLAMP MOUNTING USED FOR COMPRESSED AIR LINES RSGU 20/15
80
MOUNTING CLAMP AT SUPPORT 30/15MM
80
MOUNTING CLAMP22/15
80
CLAMPRSGU 22/20
83
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
90
SCREWM 10X20
90
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
90
SCREW BRACKET TO CAB REAR PANEL M 8X20
90
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
100
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
100
NUT HORN TO BRACKET M8
100
NUT BRACKET TO FIRE WALL
149
LINE LOW PRESSURE LINES
153
LINE LOW PRESSURE LINES
178
HOSE
190
BRACKET AT TRANSMISSION
190
BRACKET AT TRANSMISSION
199
EXPANSION HOSE FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE
202
PLATE30MM
205
RUBBER MOUNTING LINE MOUNTING 30 MM
208
LOCK
211
SCREW. HEXAGON HEAD BOLT BATTERY CABLE M6X50
214
HOSE , ORDER BY THE METER, Replaced By: A3859971582
217
220
HIGH-PRESSURE OIL LINE845 MM
223
LOW-PRESSURE OIL LINE LOW PRESSURE 1040 MM
226
229
LOW-PRESSURE OIL LINE LOW PRESSURE 1325 MM,101399
232
LOW-PRESSURE OIL LINE LOW PRESSURE 2170 MM , OM 906
235
HIGH-PRESSURE OIL LINE780 MM
238
241
244
247
250
253
256
BRACKET , Replaced By: A6285046641
