Поз.
Артикул
Описание
248
COOKER
248
BOILERVST
284
HEATING ELEMENT
286
SWITCH OVERHEATING
286
SWITCH THERMOSTAT
288
SWITCH
290
SEAL
292
RESERVOIR
300
TAKE-UP DEVICE UPPER PART
302
TAKE-UP DEVICE LOWER PART
304
SPRAY HEAD
308
HEATING ELEMENT24V/350W
312
KEY CAP BLUE
314
KEY CAP BEIGE
318
BULB24V/5W
318
BULB
320
VALVE (CHECK VALVE)
320
VALVE (CHECK VALVE)
322
PIPE SOCKET
324
SOLENOID VALVE
326
RELAY
326
RELAY24V/50A
326
RELAY24V / 40A, Replaced By: A0009823923
326
RELAY24V/50A, Replaced By: A0009823723
336
SWITCH
340
PULSE SENDER UNIT FLOW INDICATOR
342
PUMP INTERFERENCE SUPPRESSION
344
PUMP
346
LOCK RED 50A
346
LOCK GREEN 30A
346
FUSE WHITE 25A
346
FUSE LINK IN FUSE BOX AND SPARE FUSE 7,5 A
346
LOCK RUSSET BROWN 5A
999
ASHTRAY
999
COVERING ASHTRAY
999
CABLE HARNESS
999
CLUTCH
999
BOILER
999
CONTINUOUS-FLOW HEATER
999
CONTINUOUS-FLOW HEATER
999
BOILERVST
999
BOILER
999
HEATING ELEMENT
999
FILL LEVEL SENSOR
999
PLATE
999
FITTING ELBOW FITTING
999
HINGE
999
TAKE-UP DEVICE
999
COVERING
999
CUP HOLDER
999
CUP DISPENSER
999
RAIL
999
VALVE
999
BRACKET LEFT
999
CONTAINER
999
CONTAINER WATER RESERVOIR
999
CLIP
999
CLIP
999
WASHER
999
THROTTLE
999
FITTING
999
INTERIOR LAMP
999
HOSE SILICONE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
CONNECTOR
999
CABLE HARNESS
999
CONTROL UNIT CENTRAL LUBRICATION
999
CONTROL UNIT
999
COUPLING
999
SWITCH
999
ELECTRIC CABLE
999
CLIP
999
COVER
999
HOUSING
999
KITCHENETTE
999
KITCHENETTE
999
WASHER
