Поз.
Артикул
Описание
718
PIPE LINE
720
LOCK
722
PIPE LINE
724
PIPE LINE
726
PIPE LINE
728
PIPE LINE
730
PIPE LINE
732
HOSE
734
RADIATOR HOSE. HOSED14,5X23,5X100MM, Replaced By: N000000004960
736
INSULATING HOSE28MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
738
HOSE 1500 LG.
740
GROMMET
742
CLAMP STAY TO BRACKET
744
CLAMP35.6-37.3 MM
745
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
746
HOSE CLAMP. HOSE CLAMP , Replaced By: N000000000666
748
NUT , Replaced By: N913023006001
750
HOSE12X21X80MM, Replaced By: N000000004942
752
PIPE LINE
754
HOSE CLAMP. HOSE CLAMP LESS TOILET 20-21MM, Replaced By: N000000000666
999
SERVO-D.C. W.GEARBOX
999
PIPE LINE2430LG
999
PIPE LINE2450LG
999
PIPE LINED38/L2250MM
999
PIPE LINE2270LG
999
PIPE LINE
