Поз.
Артикул
Описание
11
PANELLING AIR INTAKE 199MM
14
PANELLING
17
PANELLING AIR INTAKE 199MM
23
PANELLING
29
ANGLE
32
ANGLE
35
ANGLE275LG
44
ADHESIVE TAPE
44
ADHESIVE TAPE ON BOTH SIDES 30MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
46
PAD
47
PAD
48
PAD
50
PAD
53
PAD
56
BRACKET150LG
59
RAIL
59
PAD , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
62
PAD
68
ANGLE SIDE WINDOW PANES 1735MM
80
ANGLE1000LG
83
ANGLE1090MM
84
ANGLE1090MM
84
ANGLE RIGHT
86
ANGLE LATERAL 1090MM
104
REINFORCEMENT
110
ANGLE LEFT
113
ANGLE RIGHT
116
ANGLE
119
ANGLE1090LG
125
PAD20X8X28MM
128
PANELLING DOOR CENTRAL PILLAR
131
PANELLING DOOR CENTRAL PILLAR 1198MM
134
ANGLE TOP
137
ANGLE
140
ANGLE
143
ANGLE LATERAL
146
ANGLE TOP
146
ANGLE1074LG
149
ANGLE LATERAL
152
ANGLE LATERAL
155
ANGLE LATERAL
158
ANGLE
170
PANELLING
170
PANELLING
173
PANELLING
173
PANELLING
176
PANELLING
177
PANELLING1329MM
179
PANELLING AIR INTAKE 657MM
182
ANGLE2135LG
185
ANGLE1570MM
188
ANGLE1955MM
191
ANGLE1090LG
194
ANGLE LATERAL 1090MM
197
ANGLE BOTTOM 1474LG
200
ANGLE BOTTOM 1234MM
200
ANGLE BOTTOM 1054LG
201
ANGLE
201
ANGLE
203
ANGLE704LG
203
ANGLE BOTTOM 524LG
206
ANGLE
209
ANGLE TOP 1054MM
209
ANGLE1234LG
210
ANGLE SIDE WINDOW PANES 805MM
210
ANGLE
212
ANGLE704LG
212
ANGLE TOP 524MM
215
ANGLE TOP 220LG
218
ANGLE TOP
260
ANGLE
