Поз.
Артикул
Описание
20
PLASTIC PIPE AERATION, ORDER BY THE METER
35
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
50
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
80
TEST CONNECTIONM16X1.5/M16X1.5
83
VALVE PRESSURE RELIEF
86
VALVE (QUICK-RELEASE VALVE)
86
BLEEDER VALVEBOSCH
89
PRESSURE CONTROL VALVE. RELAY VALVE PARKING BRAKE WABCO, REPAIR IMPOSSIBLE
92
VALVE TWO-WAY VALVE BOSCH,ASR
92
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
95
AXLE MODULATOR DRIVING AXLE,WEB 629001 13 520102
95
AXLE MODULATOR ,WEB 629001 13 520101
98
REDUNDANCY VALVE. VALVE (RELAY VALVE)
500
SENDER UNIT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "27" 0-10BAR
502
OIL-BREAK SWITCH VALVE UNIT, REAR OF REAR AXLE 6.5 BAR, Replaced By: A0065451114
503
SWITCH COMPRESSOR
506
CABLE PASSAGE FOR CABLE HARNESS DIA.: 18MM (100X75MM)
509
GROMMET FOR CABLE HARNESS DIA.: 14-20MM
509
GROMMET FOR CABLE HARNESS DIA.: 7-10MM
509
GROMMET
509
GROMMET
509
GROMMET
512
RETAINING CLIP
515
FITTING
518
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
521
SEAL RING RIGHT SPRING-LOAD ACCUMULATOR 10X2.2
524
LOCKS 18
527
FITTINGM22X1,5
999
CABLE TIE , Replaced By: A0049971890
999
CABLE TIE LINE MOUNTING 375X8.4MM
