Поз.
Артикул
Описание
5
COMPRESSED AIR RESERVOIR40 L
5
COMPRESSED AIR RESERVOIR AIR RESERVOIR 37L
5
RESERVOIR AIR RESERVOIR 60L
5
RESERVOIR AIR RESERVOIR 40L
5
RESERVOIR AIR RESERVOIR 37L
5
COMPRESSED AIR RESERVOIR REAR AXLE BRAKE CIRCUIT AND SECONDARY CONSUMING UNITS
5
COMPRESSED AIR RESERVOIR AIR RESERVOIR 60L
5
RESERVOIR AIR RESERVOIR 37L/DAE74281, Replaced By: A0064327801
5
RESERVOIR AIR RESERVOIR 20L, Replaced By: A0064326401
5
RESERVOIR (AIR RESERVOIR),STEEL VERSION 40L/DAE74281, Replaced By: A0064326801
5
RESERVOIR (AIR RESERVOIR),STEEL VERSION 60L, Replaced By: A0064326901
5
RESERVOIR (AIR RESERVOIR),ALUMINUM VERSION 20 L
8
RESERVOIR REGENERATION TANK 4L, Replaced By: A0064327301
8
COMPRESSED AIR RESERVOIR REGENERATION TANK 4L
11
STRAP780LG
11
STRAP875LG
14
SHACKLE
17
HEXAGON HEAD BOLTM8X90
20
NUT HORN TO BRACKET M8
23
ADHESIVE TAPE PAD FOR STRAP 50 MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0079893385
23
ADHESIVE TAPE PAD FOR STRAP 50 MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
26
VALVE DRAIN VALVE
29
SEAL RING20.3X2.4
32
THRUST RING CHECK VALVE TO AIR RESERVOIR
35
SENSOR CONDENSED WATER
38
SUPPORT
41
BRACKET
44
HEXAGON HEAD BOLT AIR DEHYDRATOR TO BRACKET M12X55,V 207570
47
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
50
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
53
SCREWM 10X20
56
SCREW , Replaced By: N910143008010
59
SCREW BRACKET TO CAB REAR PANEL M 8X20
62
SCREW SPEED SENSOR TO REAR AXLE
62
SCREW , Replaced By: N910143008000
65
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
65
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
68
NUT SUPPORTING STRUT AT BRACKET AT LEFT BOTTOM M12X1.5, A 20131120
68
NUT BRACKET TO SIDE MEMBER M12X1.5
71
NUT HORN TO BRACKET M8
74
SUPPORT TRAILING AXLE CONTROL
77
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
80
HEXALOBULAR BOLT SOLENOID VALVE TO BRACKET M8X100
80
HEXAGON HEAD BOLT. SCREW 3/2-WAY VALVE TO BRACKET M 8X100
83
SCREWM6X65
86
SCREW , Replaced By: N910143008002
89
SCREW. HEXAGON HEAD BOLT LINE MOUNTING M6X70
92
SCREW TIMING CASE COVER & TIMING CASE TO CRANKCASE
95
SPACER BUSH15X9X11LG.
98
NUT HORN TO BRACKET M8
113
FITTING12X1.5/M16X1.5 RAUFOSS
132
ELBOW FITTINGP5/12X1.5/90GR
149
FITTINGP5/M22X1.5 RAUFOSS
165
FITTINGM22X1.5/M16X1.5/M22X1.5 RAUFOSS
267
NUTM22X1.5
272
SLEEVEM22X1.5 RAUFOSS
400
VALVE , Replaced By: A0044293144
400
VALVE (OVERFLOW VALVE) WABCO
403
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
406
GROMMET
406
GROMMET
