S 416 HDH - 629.425 - 83 HEATING AND VENTILATION
Поз.
Артикул
Описание
378
DEEP FREEZER35 L
381
COVERING
384
SEAL COVER BIS 01/2002
387
FASTENER
390
HINGE
393
SPRING
396
CONNECTION
399
LATCH PLATE
402
LOCK HOUSING , STATE LOCK NUMBER WHEN ORDERING
405
COMPRESSORR134
408
CONTROL UNIT
411
CONDENSER
414
BLOWER
417
DEHYDRATOR
420
THERMOSTAT
423
INTERIOR LAMP
426
BULB24V/5W
429
SWITCH
435
KNOB
438
SCREW W SOCKET DRIVEM6X25 T30
441
REINFORCEMENT
444
COVERING
447
ANGLE TOP
450
ATTACHMENT ANGLE BRACKET
453
SCREW PIPE ELBOW TO BRACKET M8X12
456
NUT
459
SCREW , Replaced By: N910143008002
462
TAPPING SCREW4,8X60
999
BRACKET
999
LOCK
999
LOCK MAINTENANCE FLAP
999
CABLE TIE310X5MM
999
CLOSINGBN 9001
999
KEYBN 9300
