Поз.
Артикул
Описание
5
PANELLING
8
COWLING COCKPIT AREA
11
AIR DUCT
14
CONSOLE
17
CONSOLE
20
PANELLING
20
CONSOLE
23
PANELLING
26
INTERMEDIATE LAYER
29
COVER WITH CUPHOLDER
32
PANELLING
35
BRACKET PANORAMIC CAMERA
38
TAPPING SCREW MOUNTING PLATE 3.5X9.5
41
TAPPING SCREW RAIL
44
WASHER4MM
47
TRIM PANEL FEET RECESS LEG ROOM
47
PANELLING
50
CAP COVERING
53
WASHER
56
SPRING
59
FASTENER BUTTON
62
FASTENER WITH EYELET
74
COVERASTRONIC
74
COVERALLISON
77
LEDGE
80
COVERING
82
COVERING
84
ORNAMENTAL COVER
86
SHEET METAL SCREW BRACKET TO SUPPORT
86
TAPPING SCREW ATTACHMENT GRAB HANDLE
88
PANELLING
90
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
92
TAPPING SCREW HANDLE TO PANELLING
94
GLASS BRACKET
96
COVER EMERGENCY SWITCH
98
INFORMATION LABEL EMERGENCY SWITCH
100
TAPPING SCREW RAIL
102
HOUSING
104
ORNAMENTAL COVER ASHTRAY
105
PANELLING
108
PANELLING
111
AIR DUCT
114
COVER F REFRIGERATOR
117
GROMMET
120
TAPPING SCREW2,9X9,5
123
COVER MICROPHONE FIXTURE
130
REINFORCEMENT MONITOR SAUCON
133
TAPPING SCREW WIRE CABLE TO CAB 4.2X9.5
136
COVERING RAIN/LIGHT SENSOR
139
INSULATING HOSE FLEXIBLE, FOR CABLE HARNESS DIA.: 7.5 MM, ORDER BY THE METER
142
FEED-THROUGH GROMMET
