Поз.
Артикул
Описание
430
PLASTIC PIPE RISING PIPE 4X6 MM
433
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
436
UNION NUT
439
GLAND , Replaced By: A0019901667
442
SLEEVE LEAK LINE
445
PLASTIC PIPE AERATION, ORDER BY THE METER
448
FITTING (PARTS KIT),LINE RUPTURE
451
UNION NUT LINE CONNECTION
454
GLAND LINE CONNECTION
457
SLEEVE LINE CONNECTION
460
FITTING , Replaced By: N915059004001
463
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, 6 MM, VOSS 232, Replaced By: A0059972689
463
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, 6 MM, VOSS 232
466
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 6 MM, VOSS 232
469
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, 4 MM / 4 MM, VOSS 232
472
REPAIR KIT O-RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, VOSS 232
475
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M10, 4MM, SDF
475
CONNECTION PIECE , Replaced By: A0049971489
481
VALVE DRAIN VALVE
484
TEST CONNECTION
487
RESERVOIR
490
RETAINING SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M22, VOSS 232
490
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
493
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
496
FITTING
499
L-FITTINGM12X1.5/M10X1.5
502
THRUST RING CHECK VALVE TO AIR RESERVOIR
505
O-RING CHECK VALVE TO AIR RESERVOIR
508
SEAL RING 3/2-WAY VALVE
511
CABLE STRAP7.8X465
514
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
514
NUT BRACKET TO FIRE WALL
517
SCREW BRACKET AND CLAMP M6X20
517
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
520
SCREWM 10X20
523
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
526
3-2-WAY PNEUMATIC VALVE
526
SOLENOID VALVE 3/2-WAY VALVE ADBLUE
529
VALVE PRESSURE LIMIT VALVE
532
VALVE OVERFLOW VALVE ADBLUE, 7.03,V 207570V 208680
535
NON-RETURN VALVE CHECK VALVE
538
VALVE (3/2-WAY SOLENOID VALVE)
541
STRAIGHT BULKHEAD FITTING WITH O-RING M22X1.5/M16X1.5
544
SCREW PLUG SOLENOID VALVE M16
547
SCREWM6X12 TX30
550
SEAL RINGBOSCH
553
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
556
SCREW 3/2-WAY VALVE TO BRACKET
556
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M8X55
559
SCREWM6X65
559
HEXALOBULAR BOLT TRAVEL SENSOR TO BRACKET,K 186868
562
HEXALOBULAR BOLT TRAVEL SENSOR TO FRAME SIDE MEMBER M8X70,V 207570
562
SCREW , Replaced By: N910143008009
565
SPACER WASHER AT CONSOLE
568
BRACKET
571
LINED6
574
BRACKET
577
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
