Поз.
Артикул
Описание
77
SHEET METAL SCREW. SCREWST25X 6 T20
80
LOCKING CAP
487
COVERING
490
COVERING , TO BE ADAPTED DURING ASSEMBLY
499
COVERING LEFT
502
ORNAMENTAL COVER
505
BUSHING
508
BUSHING BELT LOCK MOUNTING
514
FASTENER
517
SCREWM10X32MM
562
SEAT ADAPTER
565
PLATE
571
TAPPING SCREW ORNAMENTAL COVER C-PILLAR 3.5X16
571
SHEET METAL SCREW. SCREWST25X 6 T20
577
SCREW. HEXALOBULAR BOLT MOUNTING FRAME TO SUPPORT M 8X30
580
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
592
SWITCH
593
RELAY REARVIEW MIRROR HEATING 24 V / 20 A , 32 K 06
595
SCREW4.2X32
598
LOCKING CAP
622
ELECTRIC CABLE
625
HANDLE
625
LEVER
626
SCREW BRACKET TO SIDE MEMBER M8X20
628
COVERING
664
COVERING
775
CUSHION FRAME
775
CUSHION FRAME
883
LOCK
886
LEVER
892
CUSHION COVER SEAT FOR CLIMATE-CONTROLLED SEAT, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
892
COVER SEAT CUSHION, COVER LIKE DRIVER SEAT (RECARO), DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
892
COVER SEAT CUSHION, COVER LIKE PASSENGER SEAT, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
900
CLIP
999
BUSHING
999
GRUB SCREW
