Поз.
Артикул
Описание
5
BELLOWS. BOOT
8
AIR BELLOW PISTON123 MM
11
HELPER SPRINGHOEHE 80, Replaced By: A6283210007
14
CENTERING DISCHOEHE 23
17
SCREW
20
PLATE
23
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
29
PLATED 80X15
32
HEXAGON HEAD BOLT BRACKET TO BRACKET M16X1.5X65
32
SCREW FIFTH WHEEL COUPLING TO MOUNTING PLATE M16 X 1.5 X 50
35
HEXAGON HEAD BOLT UPPER TRANSVERSE CONTROL ARM M18X1,5X6510.9
35
HEXAGON HEAD BOLT TRAILER COUPLING TO FRONT CROSS MEMBER M18X1.5X70
38
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 2 MM
38
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 4 MM
38
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 3MM
38
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 5 MM
38
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 1MM
41
HEXAGON NUT UPPER TRANSVERSE CONTROL ARM M18X1,5, Replaced By: N000000002140
41
HEXAGON NUT UPPER TRANSVERSE CONTROL ARM M18X1,5
44
SCREW LOWER CONTROL ARM
47
COMPENSATING DISC LOWER CONTROL ARM D 40X2
47
COMPENSATING DISC. THREADED UNION LOWER CONTROL ARM D 40X3
47
COMPENSATING DISC. THREADED UNION LOWER CONTROL ARM D 40X4
47
COMPENSATING DISC LOWER CONTROL ARM D 40X1
50
NUT DISC WHEELS TO FRONT AND REAR AXLES
53
SHOCK ABSORBER , ONLY REPLACEABLE BY PAIRS
56
NUTM24X1.5-14H
59
WASHER THIRD AXLE
999
SHOCK ABSORBER REPAIR KIT
