Поз.
Артикул
Описание
47
HOSE22X31X100MM
47
HOSE
89
VALVE THREE-WAY VALVE, Replaced By: A0048301684
89
VALVE THREE-WAY VALVE
92
SERVO-D.C. W.GEARBOX
92
ELECTRIC MOTOR , Replaced By: A0068207842
95
HOSE LINE CONNECTION 38X50X100 MM
95
HOSE ,D 209702
98
HOSE38X50X130MM, Replaced By: N000000004993
98
HOSE38X50X130MM
101
HEATING PIPED38/350MM
104
HEATING PIPE FEED
107
PIPE LINE RETURN
110
HEATING PIPED38/1000MM
113
HEATING PIPE
116
HEATING PIPED22/1100MM
119
HEATING PIPED22/1800MM
122
HEATING PIPED22/1350MM
125
HEATING PIPED22/1000MM
128
SLIDE
131
COVERING
134
MOLDED HOSE 90-DEGREE ARC D22
137
PIPE BEND
137
MOLDED HOSE FROM HEATING WATER PIPE TO HEATER
248
BRACKET
284
PUMP CIRCULATION PUMP 1,U4854
287
COUPLING PARTS KIT
290
CLAMP HOSE TO RETARDER 60-80X13 MM
999
"Z" SECTION60MM, Replaced By: A6279850349
