Поз.
Артикул
Описание
101
CONTAINER
107
CONTAINER
111
CONTAINER
113
HINGED DOOR LITTER-BIN
113
FLAP LITTER-BIN
114
BOTTOM
116
FIXTURE
120
FIXTURE
125
LEDGE
128
RUBBER BUFFER
131
RUBBER STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
132
ANGLE
132
ANGLE
133
PLATE SIDE PANEL
134
ELASTIC BAND
134
BAND (RUBBER TENSIONING STRAP)
135
ANGLE
137
EYELG-800 MM
138
RIVET4,0 X 10,2
140
TAPPING SCREW BRACKET TO CAB FLOOR 3.5X9.5
140
TAPPING SCREW3.5X22
140
TAPPING SCREW BRACKET MOUNTING 3.5X25
140
COUNTERSUNK WOOD SCREW4X12 T20
140
SCREW, SPECIAL SHAPE3,5X13MM
150
LOCKING CAP
150
LOCKING CAP
153
KEYHOLE COVER LITTER-BIN
153
KEYHOLE COVER LITTER-BIN
155
KEYHOLE COVER
155
KEYHOLE COVER
161
KEYHOLE COVER
161
KEYHOLE COVER
999
SPRING NUTDM 4
999
MOUNTING CLIP
999
ADHESIVE THREAD LOCK 50G
999
RING LAMINATED BRAKE
999
ELECTRICAL WIRING HARNESS FOR INNER MEMBER
999
PLATE
999
ELECTRICAL WIRING HARNESS FOR COVER
999
ELECTRICAL WIRING HARNESSFUER BUSADAPTER
999
LEDGE
999
ROD
999
COVER
999
COVER
999
ANGLE
