Поз.
Артикул
Описание
65
FRAME
71
MUFFLER
74
LOCK LEFT
77
LOCK RIGHT
80
STRIKER
83
CLIP
86
SLEEVE
89
CLAMP
92
HINGE BASE FRAME
95
RETAINING STRAP
98
RETAINING STRAP. BRACKET
110
BRACKET
113
BRACKET RIGHT CENTRAL
116
BRACKET BUMPER PANELLING,LEFT
119
BRACKET BUMPER PANELLING,RIGHT
122
BRACKET BUMPER PANELLING,RIGHT
131
SCREW , Replaced By: N910143008000
134
SCREW BUMPER TO REAR CROSS MEMBER M 8X50
137
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
140
TUBE
152
SCREW SHIFT LEVER TO BRACKET M8X30
158
SCREW , Replaced By: N910143008002
164
CYLINDRICAL HEAD SCREW. SCREW HOUSING,TOP M6X30
170
BRACKET WATER RESERVOIR
173
BRACKET WATER RESERVOIR
176
PIN
179
CLAMPING DISC
182
LOCK RING PUSH ROD TO PEDAL
185
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
188
ROLL PIN
191
LEVER
194
SLEEVE
197
WASHER BRACKET TO FUEL TANK SUPPORT
200
ROD
203
PLATE
206
SPRING
209
STRAP
211
STRAP
214
NIPPLE
217
NUT , Replaced By: N913023010002
220
NUT RELAY TO BRACKET M5
223
NUT-AND-WASHER ASSEMBLY ANTENNA AT BRACKET M4
226
WASHER COMPRESSED AIR LINE TO BRACKET
229
LOCK
232
SCREW BRACKET TO CAB REAR PANEL M 8X20
235
WASHER BRACKET TO CAB REAR PANEL
999
RUBBER BUFFER TO GLASS PANE,BOTTOM
