TRAVEGO 17 RHD 3 - ACHSER - 632.007 - 47 FUEL SYSTEM
Поз.
Артикул
Описание
11
T-FITTING
11
T-FITTING18/14/18
39
FITTING
50
FUEL HOSE
71
GROMMET
74
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
77
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
80
HOLLOW SCREW BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
86
LINE1776MM, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 02.06.2008
89
LINE
92
LINE1500MM
95
LINE1400MM
98
LINE1500MM
101
LINE1400MM
104
LINE1750 LG
110
LINE1400MM
113
LINE FEED 2010X12MM
136
FUEL HOSE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.12.2008
139
FUEL HOSE
142
LINE RETURN 760X12MM
145
LINE FEED 700X12MM
999
NUT HORN TO BRACKET M8
