Поз.
Артикул
Описание
280
HEADLINER
290
HEADLINER
300
HEADLINER
305
HEADLINER
310
HEADLINER
315
CONSOLE
804
BRACKET LEFT
806
BRACKET RIGHT
808
BRACKET
810
BRACKET
812
BRACKET LEFT
814
BRACKET RIGHT
816
BRACKET
818
EXPANSION PLUG
820
MOUNTING STRIP
822
BAND25MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
824
RUBBER SEAL4X20X920, TO BE ADAPTED DURING ASSEMBLY
824
RUBBER SEAL4X20X625, TO BE ADAPTED DURING ASSEMBLY
846
BRACKET
848
BRACKET
904
SLIDING NUTM8
906
LOCK NUT MOUNTING, COVER, THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019900856
908
SPRING NUT. LOCK COVER ATTACHMENT
910
RIVETED NUT. RIVET NUT BRACKET TO ORNAMENTAL GRILLE M6X14.5
912
SCREW , Replaced By: N910143008000
914
SCREW , Replaced By: N914146006102
914
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
916
SHEET METAL SCREW BRACKET TO SUPPORT
918
TAPPING SCREW4,2X16
920
SCREWM6X20 T30
922
NUT , Replaced By: N913023006001
