Поз.
Артикул
Описание
11
COOLING WATER PIPE RETURN LINE 60MM
14
COOLING WATER PIPE FEED LINE 60MM
17
COOLING WATER PIPE FEED LINE 60MM
20
LINE RETURN LINE 60MM
23
LINE RETURN LINE 60MM
26
HOSE12X21X850MM
32
COOLING WATER PIPE
35
BRACKET
44
BRACKET
50
BRACKET
53
MOLDED HOSE 90 DEGREES 60/60MM
53
MOLDED HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0025012082
53
COOLANT HOSE 90 DEGREES 60/60MM, Replaced By: A6285017782
62
HOSE RETURN, FROM RETARDER TO ENGINE
62
HOSE60 X 72 X 100 MM, TO BE ADAPTED DURING ASSEMBLY
65
HOSE NARROWED STRAIGHT SURFACE 70/60MM
68
HOSE RETURN, FROM RETARDER TO ENGINE
74
MOLDED HOSE 90-DEGREE ARC 60MM
77
HOSE ,D 209702
78
CONNECTOR
80
HOSE38X50X200MM
89
HOSE12X21X620MM
92
GROMMET
95
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
95
CLAMP
95
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
95
CLAMP CONNECTION OF COOLING WATER LINES 55-75X13MM
95
CLAMP HOSE TO FITTING 11 - 20 MM
113
THROTTLE
161
BASE
176
NUTM8
203
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
203
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
203
NUT , Replaced By: N913023010002
203
NUT , Replaced By: N913023006001
206
HEXAGON HEAD BOLT. SCREW BRACKET MOUNTING M8 X 30
206
HEXAGON HEAD BOLTM8X85
206
SCREW BRACKET TO SIDE MEMBER M10X35
206
SCREW , Replaced By: N910143008002
206
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M12X45
206
SCREW PICK-UP PLATE BRACKET ON LONGITUDINAL MEMBER M 14X25
206
SCREW BRACKET AND CLAMP M6X20
206
SCREWM 10X20
221
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
221
CLAMP60/25RSGU
221
MOUNTING CLAMP MOUNTING USED FOR COMPRESSED AIR LINES RSGU 20/15
221
CLAMP LINE MOUNTING
242
HOLLOW SCREW , Replaced By: N915036015201
242
HOLLOW SCREWA15
245
BANJO UNION DE-AERATION LINE TO THERMOSTAT
248
SEAL RING VALVE TO VALVE,K 025179
805
CABLE STRAP7.8X465
