Поз.
Артикул
Описание
9
BOLT AND WASHER ASSY.
9
HEXAGON HEAD BOLT
13
HEXAGON HEAD BOLT
15
HOLDING CAM
15
BUSHING
17
HEXAGON NUT
37
HEXAGON NUT
87
LOCK
87
LOCK
91
THRUST WASHER
93
RUBBER MOUNTING
141
JOINT END
143
HEXAGON NUT
147
HEXAGON NUT
149
JOINT END
177
WASHER , Replaced By: A0119908782
177
WASHER
181
COVER FOR GRAB RAIL GRIP RAIL
181
COVER FOR GRAB RAIL GRIP RAIL, Replaced By: A0008150167
183
STEP
183
FOOTPLATE
185
BUSHING
185
BUSHING
187
RETAINER WEDGE
187
FLAP F INVALID RAMP
189
END STRIP
189
CONNECTING RAIL
191
RUBBER SEAL
193
BLIND RIVET
195
BOLT WITH RECESSES , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.08.2011
195
SCREW, SPECIAL SHAPE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.07.2011
197
TORSION SPRING
199
SCREW, SPECIAL SHAPE
199
FITTED BOLT
201
WASHER
203
CYLINDER PNEUMATIC SPRING
205
BALL HEAD BOLT
207
WASHER
209
BRACKET PNEUMATIC SPRING
211
CYLINDER
211
HYDRAULIC CYLINDER
213
BOLTWITH FLAT POINT
215
LOCK WASHER
215
RETAINING RING
219
BRACKET PNEUMATIC SPRING
221
ADAPTER
223
BUSHING
225
ADAPTER
227
HEXAGON HEAD BOLT
229
COVER PNEUMATIC SPRING
231
END STOP
233
RETAINING RING
235
ROD HINGE
237
SPRING
239
SPRING
241
HINGE
241
HINGE
243
BEARING
243
FOOTPLATE SHORT
245
FILLISTER HEAD SCREW
247
SLIDING ELEMENT
249
REINFORCEMENT
251
SCREW, SPECIAL SHAPE
253
OPERATING ROD
255
RUBBING BLOCK
257
RUBBING BLOCK
257
RUBBING BLOCK
259
BEARING BRACKET
261
SCREW
263
SCREW
265
SHACKLE , Replaced By: A0008900056
265
SWIVELLING LEVER
267
PIN
269
WASHER
271
SCREW
273
GRAB RAIL
273
GRAB RAIL
273
CLAMP , Replaced By: A0008100055
273
GRAB RAIL , EXHAUST STOCK OF OLD PART NUMBER FIRST
275
COVER
277
O-RING
279
ELASTOMER WASHER
281
BALL KNOB
283
END CAP
285
END STOP GRIP RAIL
287
BOLT WITH RECESSES
290
RETAINING RING
292
LOCK
295
FASTENING STRIP
297
SCREW, SPECIAL SHAPE
299
BUSH SPECIAL SHAPE
301
BOLT
301
BOLT
303
SCREW, SPECIAL SHAPE
303
BOLT W HEAD A GROOVE
305
FITTED BOLT
305
FITTED BOLT
307
EXTENSION SPRING
469
NUT SPECIAL SHAPE
471
HEXAGON NUT5/16-18"
471
NUT5/16-20
545
SWIVELLING LEVER
545
CONNECTION STRAP , Replaced By: A0008900056
547
OPERATING ROD
553
HEXAGON NUT3/8-16
557
BUSHING
561
WASHER
603
RETAINING RING , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.08.2011
644
ANTI-SKID LINING BLACK, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.08.2011
999
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
