Поз.
Артикул
Описание
83
CABLE HARNESS ADDITIONAL CABLE,AUTOMATIC TRANSMISSION ASTRONIC, Replaced By: A6295404409
83
ELECTRICAL WIRING HARNESS ADDITIONAL CABLE,AUTOMATIC TRANSMISSION ASTRONIC, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.05.2011
86
ELECTRIC CABLE ENGINE R6, Replaced By: A6335400633
86
ELECTRIC CABLE LESS AIR CONDITIONER, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.12.2009
86
ELECTRIC CABLE ENGINE CABLE HARNESS OM 457 LA / HLA, STATE IDENT NO. WHEN ORDERING
86
ELECTRICAL WIRING HARNESS LESS AIR CONDITIONER, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.01.2010
86
ELECTRICAL WIRING HARNESS ENGINE R6
89
ELECTRICAL WIRING HARNESS. CABLE HARNESS
89
ELECTRIC CABLE DRIVE CONTROL
89
ELECTRICAL WIRING HARNESS ADAPTER CABLE INTARDER
89
ELECTRIC CABLE ADAPTER CABLE INTARDER, Replaced By: A6298201115
92
GROUND STRAP
92
GROUND STRAP24X3X450
95
BRACKET ALTERNATOR
96
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
98
SCREW BRACKET AND CLAMP M6X20
98
SCREW PIPE ELBOW TO BRACKET M8X12
98
SCREW BATTERY CABLE TO BRACKET M6X65
98
SCREW , Replaced By: N914146006102
98
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
98
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
98
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
101
CLAMP , Replaced By: N916016010211
101
CLAMP , Replaced By: A3829950701
101
CLAMP HOSE TO FLANGE AND TO VALVE
101
CLAMP CLAMP TO CROSS MEMBER 42/20
101
CLAMP LINE MOUNTING
101
CLAMP10/15
101
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
101
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
101
CLAMP DELIVERY AND SUCTION LINES TO FRAME
101
CLAMP24/15
101
CLAMP AT SUPPORT 30/15MM, Replaced By: A0019951942
104
BRACKET CABLE HARNESS AT ENGINE
107
BRACKET
116
NUT , Replaced By: N913023006001
116
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
119
BRACKET ENGINE CABLE HARNESS
122
BRACKET BRACKET TO TRANSMISSION
125
NUT RETAINER. LOCK LEFT AND RIGHT SPOILER AT CENTER PIECE
128
RETAINING CLIP
164
BRACKET AT TRANSMISSION
167
SCREW FRONT SPRINGS TO FRONT AXLE
167
HEXAGON HEAD BOLT HEAT SHIELD MOUNTING M16X1.5X30
170
BRACKET
173
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
188
CABLE CLAMP. CABLE CONNECTOR CABLE HARNESS MOUNTING
191
SHEET METAL SCREW BRACKET TO FLOOR PLATE
194
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
201
BRACKET BELOW TRANSMISSION
204
BRACKET ELECTRIC CABLE TO PREHEATER
