Поз.
Артикул
Описание
5
AIR CLEANER
6
FILTER CARTRIDGE
7
PLUG (DUST DISCHARGE VALVE)
8
FILTER BOWL
9
CONSOLE
11
RUBBER MOUNTINGM10X50X20
14
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
17
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
20
HOSE180X300MM
23
CLAMP180-200X12MM, Replaced By: N000000002136
23
CLAMP180-200X12MM
26
HOSE
26
HOSE , Replaced By: A0029978052
26
HOSE
26
HOSE
29
CLAMP150-170X12MM
29
CLAMP150-170MM
32
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
32
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
35
ELBOW FITTING
38
PLASTIC PIPE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
41
FITTING
41
ELBOW FITTING
44
HOSED25/1250LG
44
HOSE
46
BRACKET
47
BRACKET
50
BRACKET
53
HEXAGON HEAD BOLTM14X25
53
SCREW PICK-UP PLATE BRACKET ON LONGITUDINAL MEMBER M 14X25
53
HEXAGON HEAD BOLT MOUNTING, TORSION BAR, ON SIDE MEMBER M14X2X25
56
CLAMP MOUNTING USED FOR COMPRESSED AIR LINES 18/20
56
CLAMP STAY TO BRACKET
56
CLAMP CABLE HARNESS MOUNTING
56
CLAMP28/15, Replaced By: A0019951842
56
CLAMP28/20MM, Replaced By: N000000007537
59
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
59
SCREW BRACKET AND CLAMP M6X20
62
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
62
NUT , Replaced By: N913023006001
65
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
65
CLAMP25-40X13 MM
65
CLAMP HOSE TO INTAKE MANIFOLD 25-40X13MM,V 207570
69
SCREW BRACKET TO CAB REAR PANEL M 8X20
69
SCREW SHIFT LEVER TO BRACKET M8X30
71
SUPPORT
74
NUT
80
SENDER UNIT. CONTACT SENSOR
83
SEAL RING
86
HEXAGON NUT
89
CONNECTOR
90
BOX , Replaced By: A0005200002
90
RESONATOR
91
RESONATOR , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.05.2010
92
CONNECTION FITTING , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.05.2010
93
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
94
O-RING. SEAL RING COVER TO PLATE,041837
95
HOSED28/265LG
96
HOSED28/150LG
98
PROTECTIVE TUBE DIA., 28MM, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.04.2010
98
PIPE LINE
101
SCREW , Replaced By: N910143008002
103
INTAKE MANIFOLD28MM, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.05.2010
106
MOLDED HOSE AT RESERVOIR,BOTTOM D28MM
308
MOUNTING PLATE
311
SCREW , Replaced By: N910143008000
314
NUT HORN TO BRACKET M8
317
CLAMP35/20, Replaced By: N000000007514
317
CLAMP COOLING WATER HOSES
320
TEMPERATURE SENSOR. SENDER UNIT MOISTURE TEMPERATURE SENSOR, Replaced By: A0071530128
320
TEMPERATURE SENSOR MOISTURE TEMPERATURE SENSOR, Replaced By: A0071531128
320
TEMPERATURE SENSOR MOISTURE TEMPERATURE SENSOR
323
SHEET METAL SCREW IDLING ADJUSTER
326
PLATE , UNTIL PRODUCTION BREAKPOINT DATE 31.08.07
327
PLATE , AS OF PRODUCTION BREAKPOINT DATE 01.09.07
350
PLATE
353
SCREW BRACKET TO SIDE MEMBER M10X35
356
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X40
359
HOSE28X250MM
