Поз.
Артикул
Описание
5
TUBE NIROSTA 15X1,5MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
11
HOSE 90-DEGREE ARC NW15
14
HOSE
17
LINE. HOSE
20
LINE
23
HOSE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
26
FITTING
26
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
29
GLAND (DELIVERY AND SUCTION LINE) BL15
32
NUT LINE CONNECTIONS AL 15
32
UNION NUT LINE CONNECTION
38
FITTING
59
FITTING OIL LINE CONNECTION
59
FITTINGL15
62
FITTING
71
FITTING AT STEERING GEAR
71
SCREW-IN FITTING , Replaced By: N003901015005
74
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
74
FITTING POWER STEERING PUMP
77
GLANDBL22
80
UNION NUTAL22
86
LINE200MM
86
LINE1100MM
86
LINE1590MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
89
LINE1280MM
89
LINE
89
HYDRAULIC LINE WITH POWER STEERING PUMP 1180MM, AS OF PRODUCTION BREAKPOINT DATE 31.07.09
89
LINE WITH POWER STEERING PUMP 1190MM, Replaced By: A6324608724
89
LINE LESS POWER STEERING PUMP 930MM, AS OF PRODUCTION BREAKPOINT DATE 01.03.09 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
89
LINE ,WKK 629411 13 102459WKK 629411 23 102557, Replaced By: A6324608624
89
LINE1300MM
89
LINE1450MM
92
LINE22X1 MM
92
LINE1200MM
92
LINE22X1MM/757MM
92
LINE980MM
95
LINE1900MM
95
LINE1960MM
