Поз.
Артикул
Описание
46
FITTING
48
FITTING
48
HOLLOW SCREW FITTING AIR RESERVOIR,CONNECTION: "21",5 181510
50
FITTING
52
LOCK NUT
54
FITTING. OUTLETM16X1,5MM
60
CONNECTOR
92
NUT. UNION NUT RETURN
122
BANJO BOLT
122
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
130
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
150
T-FITTING
250
PLASTIC PIPE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
302
FUEL LINE
302
FUEL LINES2350MM
304
FUEL LINE1648MM
304
LINE. FUEL LINES1570MM
306
LINE
306
FUEL LINE1743MM
308
FUEL LINE1786MM
308
FUEL LINES
310
FUEL LINES
320
SUCTION LINE
320
FUEL LINE
322
SUCTION LINE
322
FUEL LINE
324
LINE
324
FUEL LINE1960MM
326
LINE1750 LG
326
FUEL LINE1788MM
500
FUEL HOSE
500
FUEL HOSE , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.12.2011 UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.04.2012
502
FUEL HOSE
504
FUEL HOSE
506
FUEL HOSE
506
FUEL HOSE
510
FUEL HOSE PLASTIC VERSION, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.01.2009
510
FUEL HOSE
510
FUEL HOSE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.12.2008
512
HOSE8X15X350MM, TO BE ADAPTED DURING ASSEMBLY
582
BRACKET
586
BRACKET
588
BRACKET
606
NUT , Replaced By: N913023006001
608
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
696
LOCK. NUT , Replaced By: A0039941745
698
NUT
706
SCREW BRACKET AND CLAMP M6X20
706
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
706
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
708
SCREW BRACKET TO CAB REAR PANEL M 8X20
808
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
810
CLAMP10/15
810
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
812
CLAMP
812
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
815
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
816
MOUNTING CLAMP16/15
816
CLAMP16/15, Replaced By: A0019950842
