Поз.
Артикул
Описание
173
BRACKET TRAILING AXLE HYDRAULIC UNIT, AS OF PRODUCTION BREAKPOINT DATE 01.03.09
176
OIL FILTER TO OIL DELIVERY LINE
179
OIL FILTER REPAIR KIT
182
VALVE TO OIL DELIVERY LINE
185
FLOW DIVIDER VALVE
185
VALVE , Replaced By: A0004606484
185
FLOW DIVIDER VALVE TO OIL DELIVERY LINE
188
LINE , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
191
LINE
194
GLAND (DELIVERY AND SUCTION LINE) BL15
197
NUT LINE CONNECTIONS AL 15
200
FITTING AT STEERING GEAR
200
SCREW-IN FITTING , Replaced By: N003901015005
203
SPACER SLEEVE
206
HEXAGON HEAD BOLT. SCREW 3/2-WAY VALVE TO BRACKET M 8X100
209
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
212
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
215
NUT , Replaced By: N913023010002
218
HEXAGON HEAD BOLT TORSION BAR TO SHACKLE M12X1.5X130
221
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
224
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
