Поз.
Артикул
Описание
65
FRAME FRONT
71
MUFFLER
74
LOCK LEFT
77
LOCK RIGHT
80
STRIKER
83
CLIP
86
SLEEVE
89
CLAMP
92
HINGE BASE FRAME
95
RETAINING STRAP
98
RETAINING STRAP. BRACKET
110
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
116
BRACKET BUMPER
116
BRACKET
119
BRACKET BUMPER PANELLING,RIGHT
122
BRACKET BUMPER PANELLING,RIGHT
131
SCREW SPEED SENSOR TO REAR AXLE
134
SCREW BUMPER TO REAR CROSS MEMBER M 8X50
137
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
140
TUBE
152
SCREW SHIFT LEVER TO BRACKET M8X30
158
SCREW , Replaced By: N910143008002
164
SCREW CONTROL SHAFT TO ENGINE
176
PIN
179
CLAMPING DISC
182
LOCK RING PUSH ROD TO PEDAL
185
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
191
LEVER
194
SLEEVE
200
ROD
203
LINK
206
SPRING
209
STRAP LEFT 2750MM
211
STRAP RIGHT 1550MM
214
NIPPLE
220
NUT RELAY TO BRACKET M5
223
NUT-AND-WASHER ASSEMBLY ANTENNA AT BRACKET M4
226
WASHER COMPRESSED AIR LINE TO BRACKET
229
LOCK
232
SCREW BRACKET TO SIDE MEMBER M8X20
235
WASHER BRACKET TO CAB REAR PANEL
999
RUBBER SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
RIVETED NUT
999
SCREW. HEXAL. SOCKET CSK. BOLTM8X30
999
DAMPING DISK
999
RUBBER BUFFER TO GLASS PANE,BOTTOM
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
WASHER4MM
999
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
