Поз.
Артикул
Описание
78
CONNECTOR
137
SCREW. HEXAGON HEAD BOLT BRACKET MOUNTING M14X1.5X25,V 207570
137
SCREW PICK-UP PLATE BRACKET ON LONGITUDINAL MEMBER M 14X25
176
NUTM8
260
COOLING WATER PIPE RETURN LINE 60MM
263
COOLING WATER PIPE FEED LINE 60MM
266
COOLING WATER PIPE FEED LINE 60MM
269
LINE RETURN LINE 60MM
272
LINE RETURN LINE 60MM
275
RADIATOR HOSE. HOSE RUBBER 12X750MM, Replaced By: N000000004956
275
HOSE12X21X850MM
278
COOLING WATER PIPE
281
BRACKET
281
BRACKET
284
BRACKET
287
BRACKET
290
BRACKET
293
BRACKET
296
MOLDED HOSE 90 DEGREES 60/60MM
296
RADIATOR HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0015013982
296
MOLDED HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0025012082
296
COOLANT HOSE 90 DEGREES 60/60MM, Replaced By: A6285017782
299
HOSE COOLING WATER LINE TO COOLING WATER LINE
299
HOSE60 X 72 X 100 MM, TO BE ADAPTED DURING ASSEMBLY
302
HOSE NARROWED STRAIGHT SURFACE 70/60MM
305
HOSE RETURN, FROM RETARDER TO ENGINE, Replaced By: N000000005010
305
HOSE RETURN, FROM RETARDER TO ENGINE
308
MOLDED HOSE 90-DEGREE ARC 60MM
311
HOSE ,D 209702
311
RADIATOR HOSE38X100MM, Replaced By: N000000004992
314
HOSE38X200MM, Replaced By: N000000004995
314
HOSE38X50X200MM
317
HOSE12X21X620MM
317
HOSE. RADIATOR HOSE12X21X620MM, Replaced By: N000000004953
320
GROMMET
323
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
323
CLAMP CONNECTION OF COOLING WATER LINES 55-75X13MM
326
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
329
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
332
CLAMP
335
SEAL RINGTO 000 553 03 05,000 553 18 05,
335
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
338
SCREW PLUGROCKINGER,TYP 59 U150
338
SCREW PLUG, FILLINGM14X1,5
338
SCREW PLUG FUEL TANK
341
THROTTLE
344
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
347
NUT , Replaced By: N913023006001
350
SCREW BRACKET AND CLAMP M6X20
353
CLAMP60/25RSGU
353
CLAMP60/25MM, Replaced By: N000000006126
356
CLAMP , Replaced By: A3829950701
356
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
359
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
359
CLAMP PIPE ON FAN SHROUD
362
HOLLOW SCREW , Replaced By: N915036015201
365
BANJO UNION DE-AERATION LINE TO THERMOSTAT
368
SEAL RING SOLENOID VALVE A 18X24
371
COOLING WATER LINE. LINE60MM
374
NUT , Replaced By: N913023010002
377
SCREWM 10X20
380
SCREW , Replaced By: N910143008002
805
CABLE STRAP7.8X465
999
HOSE LINE CONNECTION 38X50X100 MM
