Поз.
Артикул
Описание
5
STRIKER
5
STRIKER , Replaced By: A0007233803
8
SCREWM8X16
8
HEXALOBULAR BOLTM8X16
11
WASHER SHIFTING CYLINDER TO CASE
14
LOCK LEVER TO TRANSMISSION
23
SWITCH
23
SOLENOID SWITCH
26
TAPPING SCREW. SCREW FASTENING SOLONOID SWITCH 3.5X32MM
29
MAGNET
32
SCREW. TAPPING SCREW4,2X38 MM
35
WASHER PLASTIC
83
FRAME
83
DOOR FRAME900UL
84
RIVETED NUT
85
RIVET NUTM10X20
86
92
TAPPING SCREW3.5X16
95
DOOR INSIDE FRAME900UL
98
WEATHERSTRIP900UL
101
104
COVERING
107
PLATE
110
PAD
113
LATCH
116
NUT
119
TAPPING SCREW3.5X16
119
TAPPING SCREW3,5X16MM
119
TAPPING SCREW3.5X22
119
TAPPING SCREW3,5X13
120
RUBBER STRIP6X15X20
137
LEDGE
143
LEDGE
146
RAIL TOTAL RANGE OF DELIVERY, EXHAUST STOCK OF OLD PART NUMBER FIRST
146
RAIL TOTAL RANGE OF DELIVERY, Replaced By: A6337200124
149
WEATHERSTRIP TOTAL RANGE OF DELIVERY
152
LEDGE120MM
155
RAIL RIGHT
158
RAIL LEFT
161
BEARING FORMED PART , EXHAUST STOCK OF OLD PART NUMBER FIRST
161
ANGLE , Replaced By: A0007631620
164
RAIL TOP
173
ADHESIVE TAPE4.5X10 MM, ORDER BY THE METER
173
ADHESIVE TAPE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
173
ADHESIVE TAPE BETWEEN PANE AND DOOR WING 6000 MM
173
ADHESIVE TAPE3900 MM
176
LEDGE
177
RUBBER SEAL10X15MM
179
TAPPING SCREW. SCREW FASTENING SOLONOID SWITCH 3.5X32MM
210
STOP PLATE
