Поз.
Артикул
Описание
40
FITTING FUEL LINES
42
FITTINGM22/18X1,5MM
44
FITTING LINE CONNECTION
48
BANJO UNION , Replaced By: N915052006013
50
BANJO UNION HOSE WIDTH, / I.D., 6/14 MM
90
NUT. UNION NUT RETURN
90
UNION NUT FEED LINE
120
HOLLOW SCREW
124
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
130
SEALING RING. SEAL RING ENGINE BREATHING
304
FUEL LINE1050LG.D12
318
LINE240MM
326
FUEL LINE. HOSE FUEL TANK TO RING MOUNT 12 X 15 MM, ORDER BY THE METER, Replaced By: A0004763601
326
FUEL LINE15X1.5, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
336
FUEL LINE8X1, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
340
LINE12X115MM
500
SPACER SLEEVE
504
FUEL HOSE
564
GROMMET FOR CABLE HARNESS DIA.: 7-10MM
588
RANGE SPACER
606
NUT , Replaced By: N913023006001
696
LOCK. NUT , Replaced By: A0039941745
706
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
706
SCREW BRACKET AND CLAMP M6X20
706
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
808
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
812
CLAMP
812
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
815
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
816
MOUNTING CLAMP16/15
816
CLAMP16/15, Replaced By: A0019950842
838
CLAMP LINE MOUNTING
900
CABLE STRAP
