Поз.
Артикул
Описание
26
BRACKET TRANSVERSE
26
BRACKET RIGHT
26
BRACKET REAR RIGHT
26
BRACKET TRANSVERSE, REAR
29
SPACER SLEEVE
29
BUSHING SPACER
32
CLAMP
32
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
32
CLAMP HOSE TO FLANGE AND TO VALVE
32
CLAMP CLAMP TO CROSS MEMBER 42/20
32
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
32
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
32
CLAMP , Replaced By: N916016010211
32
CLAMP , Replaced By: A3829950701
32
CLAMP LINE MOUNTING
32
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM
35
NUT , Replaced By: N913023006001
38
EDGE GUARD SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
41
BRACKET
44
SCREWM 8X22, T40
47
HEXALOBULAR BOLTM8X16
47
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
47
SCREW BRACKET AND CLAMP M6X20
47
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
50
LOCK NUT. SPRING NUT MOUNTING PARTS
50
LOCK. NUT , Replaced By: A0039941745
50
SPRING-THREAD NUT PROTECTIVE PLATE
50
NUT FOR TAPPING SCREWM6
65
CONSOLE EXHAUST MUFFLER TO SUBSTRUCTURE
68
ELECTRICAL WIRING HARNESS DISPLAY:
68
ELECTRICAL WIRING HARNESS REAR DIRECTION INDICATOR
71
ADAPTER DESTINATION INDICATOR
74
WIRING HARNESS DESTINATION INDICATOR
