Поз.
Артикул
Описание
106
NUT HORN TO BRACKET M8
107
HEXAGON HEAD BOLT SOLENOID VALVE TO BRACKET M8X140
107
SCREW , Replaced By: N910143008002
107
SCREW SHIFT LEVER TO BRACKET M8X30
107
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
107
SCREW , Replaced By: N910143008010
115
SCREW. UNION SCREW , Replaced By: A0009973734
115
SCREW. UNION SCREW LINE CONNECTION
122
OIL-BREAK SWITCH VALVE UNIT, REAR OF REAR AXLE 6.5 BAR, Replaced By: A0065451114
125
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
128
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
128
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
131
131
FITTING TWO-WAY VALVE,CONNECTION: "2" M22X1.5/M22X1.5/M12X1.5
134
CONNECTOR REAR AXLE VALVE,CONNECTION: "1"
137
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
140
FITTING LOCKING VALVE
144
VALVE (QUICK-RELEASE VALVE) WABCO
145
DIAPHRAGMWABCO
146
REPAIR KIT QUICK-RELEASE VALVE WABCO, TO 004 429 23 44/25 44
147
SCREW. UNION SCREW LINE CONNECTION
149
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
152
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
155
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
158
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
161
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
161
THRUST RING CHECK VALVE TO AIR RESERVOIR
164
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
167
O-RING CHECK VALVE TO AIR RESERVOIR
170
SEAL RING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTIONS: "23"
173
MUFFLER VALVE BLEEDING
176
SEALING CORD SUCTION LINE TO OIL PUMP
178
BRACKET AT CROSS MEMBER
179
SUPPORT. APPARATUS SUPPORT DRIVING AXLE
182
BRACKET FROM MASTER CYLINDER TO CONNECTOR
185
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X40
185
SCREW BRACKET TO CAB REAR PANEL M 8X20
188
NUT HORN TO BRACKET M8
188
NUT BRACKET TO FIRE WALL
191
OVERFLOW VALVE10BAR
194
FITTING LINE CONNECTION
194
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
197
FITTING LINE CONNECTION
197
CONNECTOR REAR AXLE VALVE,CONNECTION: "1"
200
SCREW. UNION SCREW LINE CONNECTION
203
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
206
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
209
THRUST RING CHECK VALVE TO AIR RESERVOIR
209
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
212
O-RING CHECK VALVE TO AIR RESERVOIR
215
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
218
WASHER
999
HANDLE REPAIR KIT
999
VALVE REPAIR KIT
