Поз.
Артикул
Описание
5
8
11
14
ANGLE REINFORCEMENT
17
CONNECTION LEFT
18
CONNECTION RIGHT
20
23
HEXAGON HEAD BOLT TRAILER COUPLING TO FRONT CROSS MEMBER M16X1.5X45
23
HEXAGON HEAD BOLT TRAILER COUPLING TO FRONT CROSS MEMBER M16X1.5X45
26
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE
26
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE M16X1.5
62
65
BRACKET BEHIND REAR AXLE
86
BRACKET LINE MOUNTING
89
HEXAGON HEAD BOLT SHACKLE TO TORSION BAR AND TO CONSOLE M16X1.5X60
89
SCREW FIFTH WHEEL COUPLING TO MOUNTING PLATE M 16X1.5X60, IN CONJUNCTION WITH CODE: 8224
92
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE
92
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE M16X1.5
