Поз.
Артикул
Описание
122
VALVE FRONT AXLE
131
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
134
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
140
TRAVEL SENSOR SELF-LEVELLING DEVICE
143
SCREW 3/2-WAY VALVE TO BRACKET
152
ROD AIR SPRING VALVE
155
BALL SOCKET R.H. THREAD 255 MM
158
BALL SOCKET , Replaced By: A3579910622
158
BALL SOCKET BRAKE POWER REGULATOR CONTROL,5 574483
161
BALL STUD TO REAR FLOOR ASSEMBLY, LEFT AND RIGH
161
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
164
NUT
167
170
BRACKET BOTTOM LEFT,AT SHOCK ABSORBER
173
176
179
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
182
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
182
NUT
191
PROTECTION CAP MOUNTING TO BODY
194
WASHER PUMP TO CONSOLE
222
T-FITTING RELAY VALVE,CONNECTION: "10" NG12/NG12/NG12, FROM IDENT NO. WEB 105309 ALSO INSTALLED ON 104831-104930,104931-105130,105261,105268-105295,105307. EXCEPT 105317,105318,105324,105382,105388. FROM IDENT NO. VF9 300289 ALSO INSTALLED ON 300046,300282-300284.
225
FITTINGNG12/M16X1.5
228
SEAL RING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTIONS: "22"
231
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
231
RETAINING SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M22, VOSS 232
231
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
234
SCREW PLUG AIR RESERVOIR
237
PLUG SOCKET COMPRESSOR
237
PRESSURE SWITCH RELAY VALVE,CONNECTION: "21", 5.5 BAR
240
OIL-BREAK SWITCH VALVE UNIT, REAR OF REAR AXLE 6.5 BAR, Replaced By: A0065451114
243
SEAL RING 3/2-WAY VALVE
246
BRACKET
249
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM
249
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
252
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
252
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
252
SCREW BRACKET AND CLAMP M6X20
255
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
258
LOCK NUT. SPRING NUT STEP TO ENTRANCE
261
CABLE TIE LINE MOUNTING 375X8.4MM
261
LOOM TIE LINE MOUNTING
264
BRACKET ELECTRIC CABLE MOUNTING
267
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
270
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
999
999
999
