Поз.
Артикул
Описание
62
COMPRESSOR
62
COMPRESSOR , Replaced By: A6383280502
65
ANTI-FREEZE DEVICE
68
BREATHER PIPETO 638 328 03 02
71
STRAINERTO 638 328 03 02
73
SUCTION LINE , TO BE ADAPTED DURING ASSEMBLY
74
RUBBER RING (PARTS KIT)
75
VALVE
77
VALVE (SOLENOID VALVE)
77
TS AIR DEHYDRATOR SERVICE MEASURE TU 638 328 03 02
78
VALVE , Replaced By: A6383280530
80
MAGNET
83
BRACKET COMPRESSOR
83
BRACKET , Replaced By: A6383201043
86
HOSE , Replaced By: A6389974282
86
HOSE AIR SPRING VALVE,AIR SPRING BELLOWS,072615 TO BE ADAPTED DURING ASSEMBLY
89
SEAL RING PARTS KIT
92
SCREW TAIL LAMP TO SUPPORT
95
WASHER COMPRESSOR TO BRACKET
98
NUT HOOK TO BRACKET
101
HEXAGON HEAD BOLT. SCREW VALVE TO BRACKET
101
SCREW COVER PLATE TO BRACKET
104
WASHER COVER TO ALTERNATOR
105
GROMMET ,D 314239
106
BUSHING SOLENOID VALVE TO BRACKET TO A6383201143
107
BUSHING , FROM MODEL YEAR'97
107
BUSHING RANGE SELECTOR LEVER
110
SCREW BRACKET MOUNTING M6 X 20
113
WASHER CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
116
LOOM TIE LINE MOUNTING 280 MM
116
LOOM TIE , Replaced By: A0019978390
146
SENDER UNIT (TURNING ANGLE SENSOR)
146
SENDER UNIT
149
BRACKET LEFT
149
BRACKET , Replaced By: A6385420340
149
BRACKET , Replaced By: A6385420440
149
BRACKET RIGHT
152
ROD
155
SCREW BRACKET MOUNTING M6 X 20
158
SCREW SENSOR TO BRACKET M 5X10
161
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
164
CLAMP AT BRACKET
