Поз.
Артикул
Описание
10
SCREW FITTING RETURN
20
HOSE MUFFLER TO PRESSURE REGULATOR
30
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
30
LOOM TIE , Replaced By: N916017025000
40
BRACKET
50
CLAMP , Replaced By: N916016022201
50
CLAMP LINE MOUNTING
60
SCREW COVER PLATE TO COVER PLATE M 6 X 12
60
SCREW , Replaced By: N304017006018
70
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
80
NUT BALL PIVOT TO LEVER
100
SUPPORT
100
SUPPORT
110
SCREW
110
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
120
WASHER , Replaced By: N000125008443
120
WASHER EXHAUST MUFFLER TO STRAP
130
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
130
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
140
ELBOW FITTING
150
PLASTIC PIPE AERATION, ORDER BY THE METER
150
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
150
HOSE , Replaced By: A0089979082, +002A0019977672, +002N915001006000
160
FITTING RETURN LINE
200
THERMOSTAT
210
TANK
220
ADAPTER FITTING TO PLUG CONNECTION PIPE SOCKET
230
SEAL RING FUEL LINE TO FEED PUMP
240
SCREW PLUG , UP TO IDENT NO. 5 274831 EXCEPT FOR 5 264779, 5 268469
250
HOSE FROM EXPANSION TANK TO RADIATOR
280
RADIATOR CAP
320
STRAP
340
ELBOW FITTING
350
SEAL RING FUEL LINE TO FEED PUMP
360
PLASTIC PIPE AERATION, ORDER BY THE METER
360
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
360
HOSE , Replaced By: A0089979082, +002A0019977672, +002N915001006000
370
FITTING RETURN LINE
999
HOSE
999
LOOM TIE , Replaced By: N916017025000
999
BRACKET
999
CLAMP , Replaced By: N916016012205
999
CLAMP , Replaced By: N916016022201
999
LINE
999
COVER
999
PIPE
999
SCREW COVER PLATE TO BRACKET
999
SEAL RING LINE CONNECTION
999
SEAL RING , Replaced By: N007603012111
999
SCREW PLUG
999
UNION NUT FROM FUEL TANK TO THRU-WAY VALVE (FEED LINE)
999
DOUBLE FITTING FROM FUEL TANK TO THRU-WAY VALVE (FEED LINE)
999
SCREW FITTING
999
CLAMP
