Поз.
Артикул
Описание
11
GROMMET LINE THRU FRAME
14
WASHER BRACKET TO LEFT SIDE MEMBER
14
WASHER , Replaced By: A3609902340
14
WASHER , Replaced By: N009021008213
14
WASHER BRACKET TO LEFT SIDE MEMBER
15
BRACKET BREATHER LINE TO FRONT AXLE
16
SCREW , Replaced By: N304017008016
16
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
17
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
18
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
18
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
18
BRACKET LEFT COMPRESSED AIR LINES
18
BRACKET RIGHT COMPRESSED AIR LINES
18
BRACKET RIGHT COMPRESSED AIR LINES
20
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
23
SCREW PIPE CLAMP
23
SCREW , Replaced By: N304017008021
24
WASHER , Replaced By: N000125008443
24
WASHER EXHAUST MUFFLER TO STRAP
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
29
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
29
BRACKET , Replaced By: A6154200086
29
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
32
SCREW , Replaced By: N304017008034
32
SCREW BRACKET TO CROSS CONNECTION STRUT
35
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
38
BRACKET BREATHER LINE TO SIDE MEMBER
41
SCREW , Replaced By: N304017008027
41
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
46
SCREW BRACKET TO SIDE MEMBER
47
NUT , Replaced By: N910113014001
47
NUT BRACKET TO SIDE MEMBER
48
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
48
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
49
WASHER , Replaced By: N009021005205
49
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
50
NUT BRACKET TO PIN
51
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
51
BRACKET FUEL LINE TO BELL HOUSING
51
BRACKET , Replaced By: A3604292940
52
SCREW , Replaced By: N304017008021
52
SCREW , Replaced By: N304017008034
52
SCREW PIPE CLAMP
52
SCREW BRACKET TO CROSS CONNECTION STRUT
52
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
53
NUT STRAP TO BRACKET
53
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
53
NUT , Replaced By: N913004008001
53
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
53
NUT , Replaced By: N910113010000
56
BRACKET LINE TO FRONT PANEL
59
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
59
EDGE GUARD SECTION , Replaced By: A0019872272
69
BRACKET , NOT USED, Replaced By: A6554314640
69
BRACKET , Replaced By: A6554314640
69
BRACKET BRACKET TO CONTROL ARM
70
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
71
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
74
CLAMP 3/2-WAY SOLENOID VALVE
77
SCREW CLAMP TO BRACKET
77
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
80
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
WASHER COMPRESSED AIR LINE TO BRACKET
83
NUT PUMP TO BRACKET
83
NUT , Replaced By: N913004006001
86
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
89
FITTING DIAPHRAGM CYLINDER,CONNECTION:
92
UNION NUT LINE CONNECTION, Replaced By: N000000006239
92
UNION NUT LINE CONNECTION
95
SEAL CONE LINE CONNECTION
95
GLAND , Replaced By: A0019901967
98
CLAMP HOSE TO FITTING AND TO OIL TANK
98
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
101
ADAPTER FITTING LINE CONNECTION TO ENGINE
102
BRACKET BRAKE HOSE
104
NUT BRACKET TO SIDE MEMBER
105
SCREW PIPE CLAMP
105
SCREW , Replaced By: N304017008021
106
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
106
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
109
T-FITTING LEFT AND RIGHT BRAKE HOSES
110
SCREW. UNION SCREW LINE CONNECTION
113
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
116
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
119
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
122
FITTING DELIVERY LINE TO PUMP
125
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
128
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
131
FITTING DELIVERY LINE TO PUMP
132
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
133
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
134
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
135
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
137
LOCK REAR AXLE BRAKE HOSE,K 181360
140
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
140
CLAMP HOSE TO FITTING AND TO OIL TANK
143
TEST CONNECTION
143
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
LOOM TIE LINE MOUNTING
146
LOOM TIE LINE MOUNTING 280 MM
999
BRACKET COMPRESSED AIR LINES
