Поз.
Артикул
Описание
5
RADIATOR WATER
5
RADIATOR , Replaced By: A6505011201
5
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 906164, Replaced By: A6505010601
8
SCREW WATER DRAIN
11
LOCK
14
SUPPORT RADIATOR,RIGHT,K 096749
14
SUPPORT RADIATOR,RIGHT,K 096750
14
SUPPORT RADIATOR,LEFT,K 096750
14
SUPPORT RADIATOR,LEFT,K 096749
20
SCREW SUPPORT TO SIDE MEMBER
20
SCREW , Replaced By: N000961012025
23
NUT SUPPORT TO SIDE MEMBER
26
RUBBER MOUNTING RADIATOR
32
SCREW , Replaced By: N304017010028
32
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
35
WASHER RADIATOR TO RUBBER MOUNTING
35
WASHER , Replaced By: N000125010532
44
FAN SHROUD RADIATOR
47
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
59
TANK COOLING WATER EXPANSION
62
RADIATOR CAP , Replaced By: A0005016415
62
RADIATOR CAP FILLER NECK
65
SEAL RING
68
RADIATOR CAP
71
RADIATOR CAP CENTRAL
71
RADIATOR CAP CENTRAL
74
GASKET O.D., 52 MM
77
GASKET O.D., 37 MM
80
DRAIN PIPE
83
SENDER UNIT COOLING WATER LEVEL INDICATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR 48X40 MM
86
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
89
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
89
BRACKET. LOCK , Replaced By: A6525040038
92
HOSE FROM EXPANSION TANK TO RADIATOR
95
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
95
CLAMP , Replaced By: N916017011001
140
BRACKET OI DIPSTICK GUIDE TUBE
146
CLAMP OIL DIPSTICK TO RADIATOR
155
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
155
NUT , Replaced By: N913004008001
155
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
