Поз.
Артикул
Описание
5
SUPPORT
8
SCREW GUSSET PLATE TO SIDE MEMBER M 14X28
8
SCREW SUPPORT TO SIDE MEMBER M 14X45
8
SCREW , Replaced By: N308676014012
11
BRACKET TRANSFER CASE SUSPENSION,LEFT
17
SCREW STABILIZER TO BEARING
20
WASHER CROSS MEMBER TO SUPPORT
23
NUT BRACKET TO SIDE MEMBER
23
NUT , Replaced By: N910113014001
26
RUBBER MOUNTING TRANSFER CASE SUSPENSION,LEFT
29
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
32
WASHER CONSOLE TO FRAME
38
BRACKET TRANSFER CASE TO FRAME,LEFT
38
BRACKET TRANSFER CASE SUSPENSION,LEFT,5 579574
39
SUPPORT BRACKET TO FRAME
50
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
50
SCREW BEARING BRACKET TO SIDE MEMBER M 14X1.5X28
50
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
50
SCREW , Replaced By: N308676014020
51
WASHER , Replaced By: N007349015002
51
WASHER SUPPORT TO SIDE MEMBER
53
NUT BRACKET TO SIDE MEMBER
53
NUT , Replaced By: N910113014001
56
SCREW BRACKET TO SIDE MEMBER
56
SCREW SUPPORT TO CROSS MEMBER M 10X28
59
NUT STRAP TO BRACKET
59
NUT , Replaced By: N910113010000
999
SHIM BRACKET TO FRAME
