Поз.
Артикул
Описание
18
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
18
HOSE , Replaced By: A0009872827
26
FITTING , Replaced By: A0029906171
26
FITTING (PARTS KIT),LINE RUPTURE
32
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
34
T-FITTING HOSE WIDTH, 9 MM,TO M 22
34
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
34
T-FITTING , Replaced By: A0029909070
36
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
38
CONNECTOR RELEASE BEARING LUBRICATION
38
CONNECTOR , Replaced By: A0019904078
39
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
40
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
42
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
44
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
46
GROMMET LINE PASSAGE AT SIDE MEMBER
46
GROMMET LINE PASSAGE AT SIDE MEMBER
48
LOOM TIE LINE MOUNTING 280 MM
48
LOOM TIE LINE MOUNTING
54
RESERVOIR30L,246 MM,12.5 BAR
54
RESERVOIR30L,276 MM,8.5 BAR
54
RESERVOIR ,5 934167, Replaced By: A0034321801
54
RESERVOIR ,5 934167, Replaced By: A0034322501
54
RESERVOIR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 471377, Replaced By: A0014320201
54
RESERVOIR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 471377, Replaced By: A0024320401
54
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0024320801
54
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0034322101
54
RESERVOIR40L,276 MM,8.5 BAR
65
LOCK PROTECTION AGAINST TORSION,5 934167
78
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
86
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
98
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
108
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
114
SCREW. UNION SCREW LINE CONNECTION
116
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
116
FITTING LINE CONNECTION
120
THRUST RING CHECK VALVE TO AIR RESERVOIR
120
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
138
O-RING CHECK VALVE TO AIR RESERVOIR
148
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
148
SCREW PLUG , Replaced By: N000908022011
160
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
180
SUPPORT SERVICE BRAKE AIR RESERVOIR
198
CONSOLE AIR RESERVOIR TO FRAME
200
BRACKET AIR RESERVOIR
200
BRACKET AIR RESERVOIR TO FRAME
206
BASE AIR RESERVOIR TO APPARATUS SUPPORT, BOTTOM
208
SCREW END PIECE TO EXHAUST PIPE M 10X25
210
NUT STRAP TO BRACKET
210
NUT , Replaced By: N910113010000
218
BASE AIR RESERVOIR TO CONSOLE
230
STRAP AIR RESERVOIR TO BRACKET
230
STRAP SERVICE BRAKE AIR RESERVOIR
230
STRAP AIR RESERVOIR TO CONSOLE
230
STRAP , Replaced By: A6204300040
248
STRAP AIR RESERVOIR TO CONSOLE
248
STRAP , Replaced By: A6734300040
248
STRAP , Replaced By: A6734300240
252
STRAP AIR RESERVOIR TO BRACKET
252
STRAP AIR RESERVOIR TO BRACKET
252
STRAP CLUTCH BOOSTER AIR RESERVOIR 520 MM
260
SCREW END PIECE TO EXHAUST PIPE M 10X25
278
SCREW , Replaced By: N308676012018
278
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
278
SCREW , Replaced By: N308676012012
278
SCREW STRUT TO FRAME M 12X62
278
SCREWM 12X65,K 205936
278
SCREW BRACKET TO PROPELLER SHAFT BEARING HOUSING M 12X30
278
SCREW AIR RESERVOIR STRAP M 12X45,5 916821
278
SCREW , Replaced By: N308676012015
280
SCREW BRACKET TO SIDE MEMBER
284
WASHER AIR RESERVOIR STRAP,K 205936
284
WASHER AIR RESERVOIR STRAP,5 916821
284
WASHER BRACKET TO SIDE MEMBER
290
NUT EXHAUST PIPE TO SIDE MEMBER
290
NUT , Replaced By: N910113010000
290
NUT STRAP TO BRACKET
312
VALVE. DRAIN VALVE DRAIN
312
VALVE DRAIN, Replaced By: A0004322107
312
VALVE DRAIN, Replaced By: A0004322407
320
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
RESERVOIR , Replaced By: A0034321201
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
BRACKET AIR RESERVOIR
999
HOLLOW SCREW AIR RESERVOIR
999
SCREW , Replaced By: N304017008021
999
SCREW PIPE CLAMP
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
