Поз.
Артикул
Описание
11
GROMMET LINE THRU FRAME
14
WASHER BRACKET TO LEFT SIDE MEMBER
14
WASHER , Replaced By: N009021008213
14
WASHER BRACKET TO LEFT SIDE MEMBER
17
BRACKET RIGHT COMPRESSED AIR LINES
17
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
17
BRACKET LEFT COMPRESSED AIR LINES
17
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
17
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554200786
20
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
23
SCREW PIPE CLAMP
23
SCREW , Replaced By: N304017008021
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
NUT , Replaced By: N913004008001
27
WASHER EXHAUST MUFFLER TO STRAP
27
WASHER , Replaced By: N000125008443
29
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
29
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
29
BRACKET , Replaced By: A6154200086
32
SCREW BRACKET TO CROSS CONNECTION STRUT
32
SCREW , Replaced By: N304017008034
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
35
NUT , Replaced By: N913004008001
38
BRACKET BREATHER LINE TO SIDE MEMBER
41
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
41
SCREW , Replaced By: N304017008027
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT , Replaced By: N913004008001
50
SCREW BRACKET TO SIDE MEMBER
51
NUT BRACKET TO SIDE MEMBER
51
NUT , Replaced By: N910113014001
53
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
53
EDGE GUARD SECTION , Replaced By: A0019872272
54
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
54
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
55
BRACKET LINE TO FRONT PANEL
56
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
56
WASHER , Replaced By: N009021005205
59
NUT BRACKET TO PIN
60
BRACKET
61
SCREW BRACKET TO BATTERY CASE
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
NUT , Replaced By: N913004008001
63
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
65
BRACKET COMPRESSED AIR LINE TO CONTROL ARM,5 927466
66
BRACKET COMPRESSED AIR LINE TO CONTROL ARM,5 927466
68
SCREW PIPE CLAMP
68
SCREW , Replaced By: N304017008021
71
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
71
NUT , Replaced By: N913004008001
83
BRACKET FUEL LINE TO BELL HOUSING
86
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
89
NUT STRAP TO BRACKET
89
NUT , Replaced By: N910113010000
90
BRACKET , Replaced By: A6554314640
91
BRACKET BRACKET TO CONTROL ARM
91
BRACKET , NOT USED, Replaced By: A6554314640
92
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
93
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
94
CLAMP COMPRSSED AIR LINE TO SUBSTRUCTURE
95
CLAMP 3/2-WAY SOLENOID VALVE
96
CLIP COMPRSSED AIR LINE TO SUBSTRUCTURE
98
SCREW CLAMP TO BRACKET
98
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
101
WASHER COMPRESSED AIR LINE TO BRACKET
101
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
104
NUT PUMP TO BRACKET
104
NUT , Replaced By: N913004006001
107
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
110
FITTING DIAPHRAGM CYLINDER,CONNECTION:
112
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
113
UNION NUT LINE CONNECTION
113
UNION NUT LINE CONNECTION, Replaced By: N000000006239
116
SEAL CONE LINE CONNECTION
116
GLAND , Replaced By: A0019901967
119
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
119
CLAMP HOSE TO FITTING AND TO OIL TANK
122
ADAPTER FITTING LINE CONNECTION TO ENGINE
125
NUT BRACKET TO SIDE MEMBER
128
T-FITTING LEFT AND RIGHT BRAKE HOSES
131
SCREW. UNION SCREW LINE CONNECTION
146
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
149
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
150
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
151
T-FITTING DIAPHRAGM CYLINDER
152
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
153
TEST CONNECTION BULKHEAD FITTING
153
TEST CONNECTION
153
TEST CONNECTION
153
TEST CONNECTION
153
TEST CONNECTION
153
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
153
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
153
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
153
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
170
LOOM TIE LINE MOUNTING
170
LOOM TIE LINE MOUNTING 280 MM
999
BRACKET COMPRESSED AIR LINES
