Поз.
Артикул
Описание
242
SCREW. UNION SCREW LINE CONNECTION
242
SCREW. UNION SCREW , Replaced By: A0009973734
247
LOCK LINE CONNECTION
247
LOCK , Replaced By: A0009945448
252
LOCK RING LINE CONNECTION
252
SEAL RING , Replaced By: A0009940747
257
CONNECTOR HOSE WIDTH, 6 MM,TO M16
257
CONNECTOR , Replaced By: A0029905478
262
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
262
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
262
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
262
TEST CONNECTION
267
PIPE SOCKET LINE CONNECTION
272
RESERVOIR20L, 276 MM, TO VOSS 232,5 934168 FOR VEHICLES WITH VOSS 230 CONNECTOR: ADD. MOUNT FITTING "A 004 997 82 72" WITH O-RING "A 000 987 04 46" AND THRUST RING "A 000 997 02 03" TO AIR RESERVOIR
272
RESERVOIR20L, 276 MM, TO VOSS 230,5 934168, Replaced By: A0054325401, +002A0009870446, +002A0009940203, +002A0049978272
272
RESERVOIR ,5 934167, Replaced By: A0034325201
272
RESERVOIR20 L, 246 MM,5 934168
272
RESERVOIR , Replaced By: A0034325101
272
RESERVOIR , Replaced By: A0034325001
272
RESERVOIR20L,246 MM,12.5 BAR
272
RESERVOIR , Replaced By: A0034321201
272
RESERVOIR20L,276 MM,8.5 BAR
272
RESERVOIR SPRING LOAD ACCUMULATOR 20 L, Replaced By: A0034321601
277
VALVE. DRAIN VALVE DRAIN
277
VALVE. DRAIN VALVE DRAIN
277
VALVE DRAIN, Replaced By: A0004322107
277
VALVE DRAIN, Replaced By: A0004322407
282
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
287
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
287
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
290
BRACKET AIR RESERVOIR TO FRAME
292
BRACKET APPARATUS SUPPORT
297
CONSOLE AIR RESERVOIR
297
CONSOLE AIR RESERVOIR
302
SCREW PIPE CLAMP
302
SCREW , Replaced By: N304017008021
307
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
312
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
317
WASHER HOLLOW RUBBER SPRING TO CAB,5 956657
322
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
322
NUT , Replaced By: N913004008001
327
NUT STRAP TO BRACKET
327
NUT , Replaced By: N910113010000
332
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
332
SCREW , Replaced By: N308676012012
337
NUT SUPPORT TO SIDE MEMBER
342
STRAP AIR RESERVOIR TO BRACKET
342
STRAP PARTICLE FILTER
342
STRAP , Replaced By: A6554900942
347
STRAP AIR RESERVOIR TO FRAME SIDE MEMBER
352
PIN STRAP TO CONSOLE
357
COTTER PIN STRAP TO CONSOLE
362
SCREW BRACKET TO FRAME SIDE MEMBER
367
NUT STRAP TO BRACKET
367
NUT , Replaced By: N910113010000
372
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
372
SCREW , Replaced By: N304017008016
377
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
377
NUT , Replaced By: N913004008001
380
ADHESIVE TAPE60 MM, ORDER BY THE METER
999
BRACKET AIR SPRING VALVE, NOT USED
999
BRACKET REAR AXLE OPERATING ROD
