Поз.
Артикул
Описание
5
PIPE ELBOW (OIL FILLER PIPE)
26
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
29
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
29
SCREW , Replaced By: N308676012026
32
WASHER
35
NUT STRAP TO BRACKET
35
NUT , Replaced By: N910113010000
38
NUT SUPPORT TO SIDE MEMBER
41
CAP OIL REFILLING
41
CAP OIL REFILLING
41
CAP OIL REFILLING
44
GASKET
44
GASKET , Replaced By: A1020180380
47
HOSE , Replaced By: A6205280182
50
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
50
CLAMP , Replaced By: N000000000671
