Поз.
Артикул
Описание
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
5
RADIATOR WITH SCREW FITTING
5
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 752618, Replaced By: A6525012501
5
RADIATOR , Replaced By: A6525014201
8
SCREW WATER DRAIN
11
LOCK
26
RUBBER MOUNTING RADIATOR
32
SCREW LINE MOUNTING M 10X20
35
WASHER RADIATOR TO RUBBER MOUNTING
35
WASHER , Replaced By: N000125010532
44
FAN SHROUD RADIATOR
47
BOOT FAN SHROUD TO FAN RING
55
LOCK PULL TO FASTENER
55
LOCK , Replaced By: N912002008003
58
DETENT FAN SHROUD TO RADIATOR
59
TANK COOLING WATER EXPANSION
62
RADIATOR CAP FILLER NECK
62
RADIATOR CAP , Replaced By: A0005016415
65
SEAL RING
68
RADIATOR CAP
71
RADIATOR CAP CENTRAL
71
RADIATOR CAP CENTRAL
74
GASKET O.D., 52 MM
77
GASKET O.D., 37 MM
80
DRAIN PIPE
83
SENDER UNIT COOLING WATER LEVEL INDICATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
89
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
92
HOSE FROM EXPANSION TANK TO ENGINE
95
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
95
CLAMP , Replaced By: N916017011001
140
BRACKET OIL DIPSTICK GUIDE TUBE
143
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
146
BRACKET OIL DIPSTICK GUIDE TUBE
149
SCREW DE-AERATION LINE TO RADIATOR
149
SCREW , Replaced By: A6739900032
152
SCREW , Replaced By: N304017008016
152
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
155
SCREW COVER PLATE TO BRACKET
158
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
158
NUT , Replaced By: N913004008001
161
NUT LONGITUDINAL DIFFERENTIAL LOCK BRACKET,5 963747
999
SCREW , Replaced By: N304017008016
999
NUT , Replaced By: N913004008001
