Поз.
Артикул
Описание
387
SUPPORT AT CROSS MEMBER,5 317649
387
SUPPORT AT CROSS MEMBER,5 317650
396
SCREW , Replaced By: N304017008021
396
SCREW , Replaced By: N304017008034
396
SCREW BRACKET TO CROSS CONNECTION STRUT
396
SCREW PIPE CLAMP
405
NUT BRACKET TO SIDE MEMBER
405
NUT , Replaced By: N913004008001
405
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
405
NUT END PIECE TO EXHAUST PIPE
675
VALVE (REDUCTION VALVE)
675
VALVE (REDUCTION VALVE),5 359430
678
BRACKET REDUCTION VALVE
679
BRACKET REDUCTION VALVE
680
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
680
SCREW , Replaced By: N304017008016
681
SCREW , Replaced By: N304017008021
681
SCREW PIPE CLAMP
682
NUT , Replaced By: N913004008001
682
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
684
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
684
SCREW PLUG , Replaced By: N000908022011
693
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
693
THRUST RING CHECK VALVE TO AIR RESERVOIR
693
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
702
O-RING CHECK VALVE TO AIR RESERVOIR
703
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
711
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
720
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
729
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
738
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
740
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
740
VALVE FRONT AXLE II RELAY VALVE "WABCO"
740
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
740
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
740
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
740
VALVE , Replaced By: A0044293844
742
REPAIR KIT RELAY VALVE TO 003 429 93 44,WABCO
742
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
742
REPAIR KIT RELAY VALVE BOSCH
742
REPAIR KIT RELAY VALVE "GRAU"
747
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
756
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
765
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
774
O-RING CHECK VALVE TO AIR RESERVOIR
783
THRUST RING CHECK VALVE TO AIR RESERVOIR
783
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
792
NUT CHECK VALVE TO AIR RESERVOIR
801
FITTING , Replaced By: A0029979572
801
FITTING RELAY VALVE,CONNECTION: "40",5 359430
810
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
819
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
828
TEST CONNECTION
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
837
BRACKET RELAY VALVE TO CROSS MEMBER
840
BRACKET FRONT AXLE RELAY VALVE,5 585846
843
BRACKET FRONT AXLE RELAY VALVE,5 765578
846
SCREW SUPPORT TO FENDER
846
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
846
SCREW , Replaced By: N304017008027
846
SCREW , Replaced By: N304017008018
850
WASHER , Replaced By: N000125008443
850
WASHER EXHAUST MUFFLER TO STRAP
855
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
855
NUT , Replaced By: N913004008001
864
SCREW , Replaced By: N304017008027
864
SCREW , Replaced By: N304017008034
864
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
864
SCREW BRACKET TO CROSS CONNECTION STRUT
873
WASHER BRACKET TO LEFT SIDE MEMBER
873
WASHER EXHAUST MUFFLER TO STRAP
873
WASHER , Replaced By: N009021008213
873
WASHER , Replaced By: N000125008443
882
NUT , Replaced By: N913004008001
882
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
885
SCREW. UNION SCREW LINE CONNECTION
885
SCREW. UNION SCREW LINE CONNECTION
885
SCREW. UNION SCREW , Replaced By: A0009973734
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
892
SEALING CORD38X8 MM
893
SEAL RING34.6X2.6 MM
894
SEAL RING28.4X2.6 MM
895
VALVE
896
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
897
SEAL RING56X1.7 MM
898
REPAIR KIT PRESSURE RATIO VALVE
898
REPAIR KIT PRESSURE RATIO VALVE
900
BRACKET ,8 004624
902
BRACKET PRESSURE RATIO VALVE,5 585846
904
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
904
SCREW PIPE CLAMP
904
SCREW , Replaced By: A0099900101
904
SCREW , Replaced By: N304017008021
904
SCREW , Replaced By: N000933008337
909
SCREW , Replaced By: N304017008021
909
SCREW , Replaced By: A0099900101
909
SCREW , Replaced By: N000933008337
909
SCREW , Replaced By: N304017008039
909
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
909
SCREW PIPE CLAMP
909
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
910
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
910
NUT , Replaced By: N913004008001
911
FITTING AIR RESERVOIR,CONNECTION: "26", NOT USED
911
T-FITTING PRESSURE RATIO VALVE,CONNECTION: "10",8 004623
912
SCREW. UNION SCREW LINE CONNECTION
912
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
913
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
913
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
913
SCREW PLUG , Replaced By: N000908022011
914
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
915
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
915
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
916
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
917
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
920
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
924
SCREW PIPE CLAMP
924
SCREW , Replaced By: N304017008021
927
NUT , Replaced By: N913004008001
927
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
936
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
936
SCREW PLUG , Replaced By: N000908022011
938
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
959
LOOM TIE LINE MOUNTING
959
LOOM TIE LINE MOUNTING 280 MM
960
WASHER BRACKET TO LEFT SIDE MEMBER
961
RUBBER BUFFER LINE MOUNTING
962
GROMMET ,5 585846
977
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
977
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
977
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
977
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
977
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
977
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
977
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
977
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
980
SEAL RING25X2 MM,BOSCH
981
SEAL RING30X2 MM,BOSCH
982
SEAL RING33X2.5 MM,BOSCH
983
SEAL RING22X4 MM,BOSCH
983
VALVE TAPPET22X4 MM,BOSCH
984
SEAL RING"GRAU"
985
COVER SUPPLY, RED "WABCO"
985
COVER BRAKE,YELLOW "WABCO"
986
REPAIR KIT BRAKE LINE COUPLING "WABCO"
987
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "40",5 509133
988
BRACKET BRAKE LINE COUPLING TO REAR CROSS MEMBER
989
BRACKET BRAKE LINE COUPLING,"BRAKE",K 119510 FROM IDENT NO.,SEE SPECIAL VERSION 46347, 46753, 46756
990
SCREW BRACKET TO CROSS CONNECTION STRUT
990
SCREW , Replaced By: N304017008034
991
NUT , Replaced By: N913004008001
991
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
CONNECTOR BLEEDING
999
RESERVOIR , Replaced By: A0034321401
999
RESERVOIR SPRING LOAD ACCUMULATOR 20 L, Replaced By: A0034321601
999
RESERVOIR , Replaced By: A0034321201
999
PLUGTO 008 420 59 18,KNORR
999
VALVE REPAIR KIT
999
VALVE (PRESSURE LIMIT VALVE)
999
VALVE (QUICK-RELEASE VALVE) WABCO
999
VALVE (QUICK-RELEASE VALVE) WABCO
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO,5 963779 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KIT COMBINATION CYLINDER KNORR,K 186394
999
BEARING BRACKET WHEEL CYLINDER, IN CASE OF CAST AXLE
999
STRAP SPRING-LOADED BRAKE AIR RESERVOIR, Replaced By: A6554900942
999
BRACKET TRAILER CONTROL VALVE
999
GUIDE SIGN
999
LOCK FRONT AXLE RELAY VALVE
999
GUIDE SIGN LOAD-DEPENDING BRAKE,5 585845
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
STRAP AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
999
GUIDE SIGN LOAD-DEPENDING BRAKE,5 359430
999
GUIDE SIGN LOAD-DEPENDING BRAKE,5 592211
999
GUIDE SIGN LOAD-DEPENDING BRAKE,5 592211
999
BRACKET PRESSURE RATIO VALVE,5 448631
999
GUIDE SIGN LOAD-DEPENDING BRAKE
