Поз.
Артикул
Описание
5
CYLINDER HEAD
8
EXPANSION PLUG CORE HOLE 22.20 MM
11
EXPANSION PLUG CORE HOLE 40.30 MM
14
SCREW PLUG , Replaced By: N000908022011
17
SEAL RING POWER STEERING PUMP
18
SEAL RING
20
VALVE GUIDE FITTING SIZE II 18.40 MM
20
VALVE GUIDE STANDARD 18.00 MM
20
VALVE GUIDE FITTING SIZE I 18.20 MM
23
VALVE SEAT RING INTAKE,STANDARD
23
VALVE SEAT RING INTAKE, FITTING SIZE, 60.31 MM
23
VALVE SEAT RING INTAKE, FITTING SIZE, 60.51 MM
26
VALVE SEAT RING EXHAUST,FITTING SIZE, 53.31 MM, 402 265215 421-423 139488 402 266250 421-422 171870
26
VALVE SEAT RING EXHAUST,STANDARD 53.11 MM, 402 265215 421-423 139488 402 266250 421-422 171870
26
VALVE SEAT RING EXHAUST,FITTING SIZE, 53.51 MM, 402 265215 421-423 139488 402 266250 421-422 171870
29
INTAKE VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 671311, Replaced By: A4420500526
29
INTAKE VALVE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 621844, Replaced By: A4420500226
29
INTAKE VALVE
32
EXHAUST VALVE
32
EXHAUST VALVE , 402 265215 421-423 139488 EXHAUST STOCK OF OLD PARTS UP TO ENGINE 674807, Replaced By: A4420500327
35
VALVE SPRING INNER,INTAKE VALVE AND EXHAUST VALVE
35
VALVE SPRING INNER,INTAKE VALVE AND EXHAUST VALVE
35
VALVE SPRING INNER,INTAKE VALVE AND EXHAUST VALVE
38
VALVE SPRING OUTER,INTAKE VALVE AND EXHAUST VALVE
38
VALVE SPRING OUTER,INTAKE VALVE AND EXHAUST VALVE
38
VALVE SPRING OUTER,INTAKE VALVE AND EXHAUST VALVE
41
SHIM INSIDE
44
SHIM OUTSIDE
47
SPRING RETAINER
50
VALVE COLLET
50
VALVE COLLET
53
BOOT VALVE STEM SEALING
56
BEARING BRACKET ROCKER ARM
59
BALL
62
ROCKER ARM
62
ROCKER ARM
65
SET SCREW (SET SCREW)
65
SET SCREW , Replaced By: A4420550020
68
NUT , Replaced By: A4229900051
68
NUT
71
WASHER LINE MOUNTING, FROM MODEL YEAR '98017941 DISCONTINUED,PART IS NO LONGER REQUIRED
74
LOCK RING RELEASE SHAFT,BOTTOM
77
SCREW PULLEY TO VIBRATION ABSORBER
80
CYLINDER HEAD GASKET , ALSO APPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED
80
CYLINDER HEAD GASKET , ALSO APPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED
80
CYLINDER HEAD GASKET , INAPPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED, Replaced By: A4420160020
80
CYLINDER HEAD GASKET , Replaced By: A4420160520
80
CYLINDER HEAD GASKET , Replaced By: A4420160320
80
CYLINDER HEAD GASKET , Replaced By: A4420160420
80
CYLINDER HEAD GASKET , CYLINDER HEAD GASKET WITH 2 NOTCHES (THICKER BY 0.1MM),ONLY FOR USE WITH SUPPORTING SURFACE REWORKED, Replaced By: A4420160220
80
CYLINDER HEAD GASKET , INAPPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED, Replaced By: A4420160220
80
CYLINDER HEAD GASKET , CYLINDER HEAD GASKET WITH 2 NOTCHES (THICKER BY 0.1MM),ONLY FOR USE WITH SUPPORTING SURFACE REWORKED, Replaced By: A4420160020
80
CYLINDER HEAD GASKET , INAPPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED, Replaced By: A4420160020
83
SCREW CYLINDER HEAD TO CYLINDER CRANKCASE
83
SCREW CYLINDER HEAD TO CYLINDER CRANKCASE
83
SCREW CYLINDER HEAD TO CYLINDER CRANKCASE 109 MM,129761 REPLACE THE OLD PARTS FOR THE NEW ONES ON EVERY CYLINDER BY THE SET ONLY
86
NOZZLE HOLDER WITH NOZZLE
89
SPACER WASHER1.72 MM
89
SPACER WASHER1.38 MM
89
SPACER WASHER0.94 MM
89
SPACER WASHER1.16 MM
89
SPACER WASHER1.58 MM
89
SPACER WASHER0.84 MM
89
SPACER WASHER1.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
89
SHIM, 1.30 MM THICK. SPACER WASHER1.3 MM
89
SPACER WASHER1.36 MM
89
SHIM, 1.95 MM THICK. SPACER WASHER1.95 MM
89
SHIM, 1.15 MM THICK. SPACER WASHER1.15 MM
89
SPACER WASHER , Replaced By: A0040171252
89
SPACER WASHER0.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
89
SPACER WASHER1.56 MM
89
SHIM, 1.85 MM THICK. SPACER WASHER , Replaced By: A0040172852
89
SPACER WASHER , Replaced By: A0030179252
89
SHIM, 1.35 MM THICK. SPACER WASHER1.34 MM, Replaced By: A0030177852
89
SHIM, 1.0 MM THICK. SPACER WASHER1.0 MM
89
SPACER WASHER1.92 MM
89
SHIM, 1.40 MM THICK. SPACER WASHER , Replaced By: A0030178452
89
SPACER WASHER1.76 MM
89
SHIM, 1.65 MM THICK. SPACER WASHER1.65 MM
89
SPACER WASHER1.12 MM
89
SPACER WASHER0.80 MM
89
SHIM, 1.10 MM THICK. SPACER WASHER1.1 MM
89
SHIM, 1.55 MM THICK. SPACER WASHER1.55 MM
89
SPACER WASHER1.52 MM
89
SPACER WASHER1.08 MM
89
SHIM, 1.70 MM THICK. SPACER WASHER , Replaced By: A0040171452
89
SHIM, 1.25 MM THICK. SPACER WASHER1.24 MM
89
SPACER WASHER1.88 MM, Replaced By: A0040173252
89
SHIM, 1.60 MM THICK. SPACER WASHER1.6 MM
89
SHIM, 1.20 MM THICK. SPACER WASHER1.2 MM
89
SHIM, 1.45 MM THICK. SPACER WASHER1.45 MM
89
SHIM, 1.50 MM THICK. SPACER WASHER1.50 MM, Replaced By: A0030179452
89
SPACER WASHER1.78 MM, Replaced By: A0040172252
89
SPACER WASHER1.18 MM
89
SPACER WASHER0.90 MM
89
SHIM, 1.05 MM THICK. SPACER WASHER1.04 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
89
SHIM, 1.75 MM THICK. SPACER WASHER1.75 MM
89
SPACER WASHER0.88 MM
89
SHIM, 1.80 MM THICK. SPACER WASHER1.80 MM, Replaced By: A0040172452
89
SPACER WASHER1.28 MM
89
SHIM, 1.90 MM THICK. SPACER WASHER1.9 MM
89
SPACER WASHER1.70 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
89
SPACER WASHER1.96 MM
89
SPACER WASHER1.32 MM
92
PRESSURE SPRING
95
SPACER WASHER AS REQUIRED
95
SHIM , Replaced By: A0010179452
98
CLAMPING PINTO 345 017 73 21
101
CLAMPING PINTO 345 017 73 21, FOR USE WITH NOZZLE HOLDER HAVING 24X1.5-MM-THREAD UNION NUT
104
PIN
107
UNION NUT , Replaced By: A0000173316
107
UNION NUT (NOZZLE RETAINING NUT) TO 001 017 17 21
110
NOZZLE
125
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3880170160
125
SEAL RING NOZZLE HOLDER TO CYLINDER HEAD 1.5 MM
125
SEAL RING AS REQUIRED 0.5 MM
128
SCREW NOZZLE HOLDER TO CYLINDER HEAD
131
PLUG NOZZLE HOLDER TO CYLINDER HEAD
134
CYLINDER HEAD COVER
135
CYLINDER HEAD COVER
156
GASKET CYLINDER HEAD COVER TO CYLINDER HEAD
156
GASKET , Replaced By: A4420160621
156
GASKET , Replaced By: A4420160721
156
GASKET , Replaced By: A4420160621
156
GASKET , Replaced By: A4420160621
156
GASKET CYLINDER HEAD COVER
163
SCREW ,R 034014
170
SPRING WASHER BRAKE SHOE WITH LINING
177
BREATHER LINE
177
BREATHER LINE , Replaced By: A4762000158
184
HOLLOW SCREW BREATHER LINE TO CYLINDER HEAD
191
SEAL RINGTO 000 553 03 05,000 553 18 05,
198
GASKET KIT , Replaced By: A4760100420
198
GASKET KIT CYLINDER HEAD
999
CYLINDER HEAD COVER
999
CYLINDER HEAD GASKET , Replaced By: A4420160520
999
CYLINDER HEAD GASKET , Replaced By: A4420160420
999
GASKET EXHAUST MANIFOLD TO CYLINDER HEAD
999
GASKET , Replaced By: A4421410480
999
UNION NUTTO 345 017 73 21
