Поз.
Артикул
Описание
39
COVERING CHASSIS
39
ANTINOISE CAPSULE CHASSIS
39
ANTINOISE CAPSULE CHASSIS
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COVERING TO CAB
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
90
BRACKET RIGHT
90
BRACKET LEFT
90
BRACKET RIGHT
90
BRACKET LEFT
92
BRACKET RIGHT FENDER,5 385158
92
BRACKET RIGHT FENDER,5 385157
92
BRACKET LEFT FENDER,5 385158
92
BRACKET LEFT FENDER,5 385157
96
SCREW SUPPORT TO FENDER
96
SCREW , Replaced By: N304017008018
96
SCREW END PIECE TO EXHAUST PIPE M 10X25
100
WASHER BRACKET TO LEFT SIDE MEMBER
100
WASHER , Replaced By: N009021008213
100
WASHER RADIATOR TO RUBBER MOUNTING
100
WASHER , Replaced By: N000125010532
104
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
104
NUT , Replaced By: N913004008001
104
NUT STRAP TO BRACKET
104
NUT , Replaced By: N910113010000
108
BRACKET FENDER
108
BRACKET FENDER
108
BRACKET FENDER
108
BRACKET FENDER
112
SCREW BRACKET TO CROSS CONNECTION STRUT
112
SCREW BRACKET TO CROSS CONNECTION STRUT
112
SCREW , Replaced By: N304017008034
116
WASHER EXHAUST MUFFLER TO STRAP
116
WASHER EXHAUST MUFFLER TO STRAP
116
WASHER , Replaced By: N000125008443
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
NUT , Replaced By: N913004008001
126
BRACKET BRACKET TO CROSS MEMBER
128
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
128
SCREW REAR EXHAUST PIPE TO MUFFLER
128
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
128
SCREW , Replaced By: N304017008027
132
WASHER EXHAUST MUFFLER TO STRAP
132
WASHER RADIATOR TO RUBBER MOUNTING
132
WASHER , Replaced By: N000125010532
132
WASHER EXHAUST MUFFLER TO STRAP
132
WASHER , Replaced By: N000125008443
136
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
136
NUT STRAP TO BRACKET
136
NUT , Replaced By: N910113010000
136
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
136
NUT , Replaced By: N913004008001
140
SCREW PIPE CLAMP
140
SCREW PIPE CLAMP
140
SCREW , Replaced By: N304017008021
144
WASHER EXHAUST MUFFLER TO STRAP
144
WASHER EXHAUST MUFFLER TO STRAP
144
WASHER , Replaced By: N000125008443
148
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
148
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
148
NUT , Replaced By: N913004008001
156
MOUNTING ANGLE RIGHT
156
MOUNTING ANGLE RIGHT,5 385157
156
MOUNTING ANGLE LEFT,5 385158
156
MOUNTING ANGLE LEFT,5 385157
156
MOUNTING ANGLE RIGHT
156
MOUNTING ANGLE LEFT,5 385158
160
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
160
SCREW BRACKET TO CAB MOUNTING CONSOLE
160
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
160
SCREW BRACKET TO CAB MOUNTING CONSOLE
164
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
164
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
164
WASHER , Replaced By: N000125015019
168
NUT BRACKET TO SIDE MEMBER
168
NUT BRACKET TO SIDE MEMBER
172
BRACKET (BRACING)
172
STIFFENING RIGHT,5 385157
172
BRACKET (BRACING)
172
STIFFENING LEFT,5 385157
172
BRACKET (BRACING)
172
BRACKET (BRACING)
174
BRACKET RIGHT,5 385158
174
BRACKET LEFT
174
BRACKET RIGHT,5 385158
174
BRACKET LEFT
176
SCREW END PIECE TO EXHAUST PIPE M 10X25
176
SCREW BRACKET TO CROSS CONNECTION STRUT
176
SCREW PIPE CLAMP
176
SCREW BRACKET TO SIDE MEMBER
176
SCREW , Replaced By: N304017010002
176
SCREW END PIECE TO EXHAUST PIPE M 10X25
176
SCREW END PIECE TO EXHAUST PIPE M 10X25
176
SCREW END PIECE TO EXHAUST PIPE M 10X25
176
SCREW BRACKET TO CROSS CONNECTION STRUT
176
SCREW , Replaced By: N304017008034
176
SCREW PIPE CLAMP
176
SCREW , Replaced By: N304017008021
180
WASHER RADIATOR TO RUBBER MOUNTING
180
WASHER EXHAUST MUFFLER TO STRAP
180
WASHER RADIATOR TO RUBBER MOUNTING
180
WASHER RADIATOR TO RUBBER MOUNTING
180
WASHER RADIATOR TO RUBBER MOUNTING
180
WASHER RADIATOR TO RUBBER MOUNTING
180
WASHER , Replaced By: N000125010532
180
WASHER EXHAUST MUFFLER TO STRAP
180
WASHER , Replaced By: N000125008443
184
NUT STRAP TO BRACKET
184
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
184
NUT STRAP TO BRACKET
184
NUT STRAP TO BRACKET
184
NUT STRAP TO BRACKET
184
NUT STRAP TO BRACKET
184
NUT , Replaced By: N910113010000
184
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
184
NUT , Replaced By: N913004008001
186
BRACKET (BRACING)
192
MOUNTING ANGLE COVERING, TO BE ADAPTED DURING ASSEMBLY
192
MOUNTING ANGLE , Replaced By: A6205240210
192
MOUNTING ANGLE COVERING, TO BE ADAPTED DURING ASSEMBLY
192
MOUNTING ANGLE , Replaced By: A6205240210
200
SCREW BRACKET TO CROSS CONNECTION STRUT
200
SCREW BRACKET TO CROSS CONNECTION STRUT
200
SCREW , Replaced By: N304017008034
204
WASHER BRACKET TO LEFT SIDE MEMBER
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER BRACKET TO LEFT SIDE MEMBER
204
WASHER , Replaced By: N009021008213
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER , Replaced By: N000125008443
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET COVERING
244
BRACKET , Replaced By: A6555240040
244
BRACKET , Replaced By: A6555240040
244
BRACKET COVERING,5 736351
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET , Replaced By: A6735460243
244
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
244
BRACKET LEFT
244
BRACKET COVERING
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET , Replaced By: A6205240340
248
BRACKET COVERING
248
BRACKET COVERING
252
SCREW REAR EXHAUST PIPE TO MUFFLER
252
SCREW REAR EXHAUST PIPE TO MUFFLER
252
SCREW REAR EXHAUST PIPE TO MUFFLER
256
SCREW END PIECE TO EXHAUST PIPE M 10X25
256
SCREW END PIECE TO EXHAUST PIPE M 10X25
256
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
256
SCREW REAR EXHAUST PIPE TO MUFFLER
256
SCREW END PIECE TO EXHAUST PIPE M 10X25
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER BRACKET TO FRAME
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER , Replaced By: N000125010532
264
NUT STRAP TO BRACKET
264
NUT STRAP TO BRACKET
264
NUT STRAP TO BRACKET
264
NUT STRAP TO BRACKET
264
NUT , Replaced By: N910113010000
264
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
264
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
264
NUT , Replaced By: N913004008001
268
SCREW PIPE CLAMP
268
SCREW , Replaced By: N304017008021
272
WASHER EXHAUST MUFFLER TO STRAP
272
WASHER , Replaced By: N000125008443
276
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
276
NUT , Replaced By: N913004008001
280
SCREW BRACKET TO SIDE MEMBER
280
SCREW BRACKET TO SIDE MEMBER
280
SCREW , Replaced By: N304017010002
284
WASHER RADIATOR TO RUBBER MOUNTING
284
WASHER RADIATOR TO RUBBER MOUNTING
284
WASHER RADIATOR TO RUBBER MOUNTING
284
WASHER , Replaced By: N000125010532
288
NUT STRAP TO BRACKET
288
NUT STRAP TO BRACKET
288
NUT STRAP TO BRACKET
