Поз.
Артикул
Описание
161
VALVE SELF-LEVELLING DEVICE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
164
BOOT
167
REPAIR KIT AIR SPRING VALVE
170
VALVE REAR AXLE SELF-LEVELLING DEVICE
173
VALVE REAR AXLE SELF-LEVELLING DEVICE
182
MUFFLER TRAILER CONTROL VALVE
185
SEALING CORD11.3X2.4
188
SEAL RING30.0X2.0
188
SEAL RING , NOT USED
191
REPAIR KITTO 388 997 88 36
194
REPAIR KIT AIR SPRING VALVE
194
REPAIR KIT AIR SPRING VALVE, ORDER ADDITIONALLY: 1 X A 000 320 12 58
197
BRACKET AIR SPRING VALVE
200
BRACKET AIR SPRING VALVE
203
LEVER SELF-LEVELLING DEVICE
203
LEVER AIR SPRING VALVE
203
LEVER SELF-LEVELLING DEVICE
206
BALL PIVOT BOTTOM B13X5 MM
209
PULL ROD PNEUMATIC SUSPENSION CONTROL
212
YOKE BOTTOM
215
NUT
215
NUT , Replaced By: N304035008001
218
NUT L.H. THREAD
218
NUT , Replaced By: N304035008002
221
YOKE TOP
224
ANGLE LINE MOUNTING
227
LEVER TRAVEL SENSOR, TO BE ADAPTED DURING ASSEMBLY
227
LEVER , Replaced By: A9453200627
230
BALL STUD. BALL PIVOT TOP B10X4,5 MM
233
ROD TRAVEL SENSOR
233
BALL JOINT TRAVEL SENSOR
233
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008426
236
BRACKET OIL LINE MOUNTING
999
AIR CLEANER ,5 760168K 154651
999
MAGNET
999
MAGNET CONNECTION OF COMPRESSED AIR LINES
999
MAGNET ,5 760168K 154651
999
PROTECTIVE CAPWABCO
999
RUBBER MOUNTING SHACKLE TO TORSION BAR
999
SPACER WASHER LINK TO CONSOLE
999
BUSHING LINK TO CONSOLE, INAPPLICABLE TO IDENT NO.: 5 545417,5 545468,5 549721,5 549753,5 551382,5 553458,5 556586,5 556951,5 557200,5 568184,5 568795,5 575157,5 575986.K 054776
999
SPACER WASHER TORSION BAR MOUNTING
999
BUSHING TORSION BAR TO BEARING BRACKET
999
PIN TORSION BAR TO SHACKLE, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
SCREW BEARING BRACKET TO FRAME M 14X20, MODEL 415/416/417 FOR USE WITH SHORT CAB MERCEDES BENZ
999
LOCK RING SHACKLE TO TORSION BAR
