Поз.
Артикул
Описание
110
VALVE (3/2-WAY SOLENOID VALVE) EKS
113
PROTECTIVE CAPWABCO
116
SEAL RINGBOSCH
116
SEAL RINGWABCO
119
SEAL RINGBOSCH
122
GASKET KITKNORR
125
SCREW VALVE TO BRACKET
125
SCREW VALVE TO BRACKET, Replaced By: N304014008002
128
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
128
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
128
NUT , Replaced By: N913004008001
131
BRACKET 3/2-WAY SOLENOID VALVE
131
BRACKET 3/2-WAY SOLENOID VALVE
134
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
134
SCREW , Replaced By: N304017008016
137
WASHER EXHAUST MUFFLER TO STRAP
137
WASHER , Replaced By: N000125008443
140
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
143
HOLLOW SCREW HEATING CONNECTION
146
SEAL RING LINE CONNECTION
149
SCREW TO PLUG THE FREE CONNECTIONS
152
SEAL RINGBOSCH
161
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
164
SCREW TWO-WAY VALVE TO BRACKET
167
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
167
WASHER , Replaced By: N009021005205
170
NUT TWO-WAY VALVE TO BRACKET
173
BRACKET 3/2-WAY SOLENOID VALVE
176
BRACKET CONNECTOR TO FRAME
179
SCREW CLAMP MOUNTING M 6X16
179
SCREW , Replaced By: N000000001146
182
NUT PUMP TO BRACKET
182
NUT , Replaced By: N913004006001
185
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
188
HOLLOW SCREW FUEL LINE TO FEED PUMP
188
HOLLOW SCREW , Replaced By: N915036010108
191
SEAL RING FUEL LINE TO FEED PUMP
200
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL BOSCH
200
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL WABCO
203
REPAIR KIT 3/2-WAY VALVE WABCO
206
SPRING WASHER AT CAB FLOOR
209
NUT SUCTION LINE TO OIL PUMP
212
SCREW. UNION SCREW LINE CONNECTION
212
SCREW. UNION SCREW , Replaced By: A0009973734
215
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
215
BREATHER , Replaced By: A3933280065
218
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
218
SCREW PLUG , Replaced By: N000908012009
221
SEAL RING LINE CONNECTION
999
BRACKET BRACKET TO ENGINE,REAR
999
SHIM 3/2-WAY SOLENOID VALVE
