Поз.
Артикул
Описание
5
BEARING BRACKET CLUTCH PEDAL AND BRAKE PEDAL
5
BEARING BRACKET , Replaced By: A6502900319
8
STUD
11
GASKET BEARING BRACKET TO FIRE WALL
14
WASHER EXHAUST MUFFLER TO STRAP
14
WASHER , Replaced By: N000125008443
17
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
17
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
17
NUT , Replaced By: N913004008001
20
STOP CLUTCH PEDAL,5 957975
21
BRACKET CLUTCH PEDAL,5 957976
23
STOP BRAKE PEDAL
26
SCREW COVER PLATE TO BRACKET
29
NUT PUMP TO BRACKET
29
NUT , Replaced By: N913004006001
32
STOP CLUTCH PEDAL AND BRAKE PEDAL
35
PEDAL CLUTCH
35
PEDAL , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 957975, Replaced By: A6572900616
35
PEDAL , Replaced By: A6452901316
35
PEDAL CLUTCH
35
PEDAL , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 957975, Replaced By: A6572900516
38
PEDAL BRAKE
38
PEDAL BRAKE
41
PAD CLUTCH PEDAL
44
PAD BRAKE PEDAL
47
NEEDLE BEARING CLUTCH PEDAL
47
NEEDLE BEARING CLUTCH PEDAL
50
SPACER TUBE CLUTCH PEDAL
53
BUSHING BRAKE PEDAL
53
BUSHING , Replaced By: A1242920050
56
WASHER CLUTCH PEDAL TO BEARING BRACKET
59
PIN CLUTCH PEDAL TO BEARING BRACKET
62
PIN BRAKE PEDAL TO BEARING BRACKET
65
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
68
SCREW PUMP TO BRACKET
68
SCREW , Replaced By: N304017006016
71
WASHER COMPRESSED AIR LINE TO BRACKET
71
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
104
SENDER UNIT CLUTCH OPERATION EPS, TO BE ADAPTED DURING ASSEMBLY
104
SENDER UNIT , Replaced By: A6555400017
113
SCREW SWITCH TO ENGINE
116
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
122
ANGLE AT CLUTCH PEDAL UNIT
125
SCREW SWITCH TO ENGINE
128
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
131
ROD TWO-CIRCUIT-BRAKE-VALVE CONTROL
131
ROD , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732920032, +001N071752008003
134
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
134
YOKE OPERATING ROD,K 202311
137
NUT
137
NUT , Replaced By: N304035008001
140
PIN ROD TO BRAKE PEDAL
143
WASHER BRACKET TO CROSS MEMBER
146
COTTER PIN LEVER TO ROD
146
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
149
SPRING CLUTCH-PEDAL/BRAKE-PEDAL RESET
999
PAD , Replaced By: N040621014200
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
